Product and cable variants
HMEC 26-2 | 23
Product and cable variants
The following cables, connectors, control units and features
are available for the HMEC 26-2 variants (see table on the
following pages):
1 Headphhones with +6 dB characteristic SPL
2 Microphone with 60 mV output voltage
3 Single-sided round cable, 1.7 m
4 XLR-5 connector
5 ¼“ (6.3 mm) jack plug (headphones)
6 PJ-068 equivalent (microphone)
7 8-pin Neutricon connector
8 6-pin Redel connector
9 XLR-6 connector
< XLR-3 connector
A Aircraft powered
B Battery powered
C Control unit I (see page 9)
D Control unit II (see page 10)
E Audio cable (1 cable with 2.5 mm jack plugs and
1 cable with 3.5 mm jack plugs)
F Belt clip
G Carry bag
