Putting the RS 5200 into operation
14 | RS 5200
Connection possibility C: RCA sockets (analog)
▷ Plug the RCA adapter onto the stereo audio cable.
▷ Connect the stereo audio cable to the blue 3.5 mm jack socket of
the transmitter.
▷ Connect the RCA connectors to the RCA sockets (mostly labeled
“AUDIO OUT” or ) of your audio source. Connect the red con-
nector to the red RCA socket and the white connector to the white
or black RCA socket.
Connection possibility D: SCART socket (analog)
▷ Plug the SCART adapter* onto the stereo audio cable.
▷ Connect the stereo audio cable to the blue 3.5 mm jack socket of
the transmitter.
▷ Connect the SCART connector to the SCART socket (mostly
labeled or ) of your audio source.
* optional accessory
C
Analog Audio
AUDIO OUT
LR
1A
D
Analog Audio
*
1A
