Mean Airway Pressure
(MAP) is the average
pressure (amplitude +
CPAP) in the lung over
5 seconds.
Pulse Frequency Rate
represents the number of
pulses per minute.
Usage Timer displays the
total time of the current
usage.
D
Pulsating Bar Graph
measuring pulse amplitude
(0-50 cmH
2
O). PEEP is
represented by a solid bar
at the base and Average
Inspiratory Pressure (AIP)
is represented by the
pulsating peaks of the Bar
Graph display.
NOTE: Display numbers are
for reference only.
Digital Display Troubleshooting
NOTE: Refer to the Instruction Manual for the
IPV®-1C for warnings, cautions, and additional
information. Always follow hospital protocol and
use good clinical judgement when delivering IPV®
therapy. Absolute contraindications for IPV®
usage include untreated tension pneumothorax
and/or an untrained or unskilled operator.
Digital display o
The IPV® pressure must be > 2.5 cmH
2
O at the Phasitron
before the display turns on. Consider occluding the end
of the Phasitron, allowing the Digital Display to read 2.5
cmH
2
O to wake digital display. Check connections and/or
the digital display baery.
Nebulizer not aerosolizing
Ensure there is liquid present in the nebulizer cup and check
for ow out of the nebulizer bale. Disconnect the yellow
tubing and verify ow. If ow is present, turn the Master
Switch to the OFF position and reconnect the yellow tubing
to the nebulizer bowl. If the issue persists, contact product
support.
Slow or no percussions
Check that the inlet gas source is properly connected.
Check the device to ensure the Master Switch is in the ON
position, increase the Operational Pressure by turning the
knob to the right, and adjust the Percussion knob for a
higher rate. Finally, check the green REMOTE connector for
blockage. If issue persists, contact service.
