Sentinel ELIMINATOR Installation Manual

Eliminator V2-C M-03-17
EN
8
DRAIN VALVE OPERATION
To Open:
Remove end cap from bottom of
valve. Remove retaining nut, take off
handle and flip over. Replace handle
and turn to open valve, as per Figures
7 & 8.
To Close:
Turn valve to closed position, take off
handle, flip over and replace retaining
nut. Replace end cap.
BLEED VALVE OPERATION
After filling the system with water,
open bleed valve using a suitable
screwdriver to release air trapped in
filter. Once water starts to escape,
close valve. After the system has
been running for several hours,
repeat to release any trapped air.
Nut
Fig. 7
Nut
Fig. 8
