Drawing

No.

Part No. Description Quantity

1 V3175TC-01 Front Cover Assembly 1

2 V3107-01 Drive Motor 1

3 V3106-01 Drive Bracket and Spring Clip 1

4 V3818TC Circuit Board 4 Digit 1

5 V3110 Drive Reducing Gear 3

6 V3109 Drive Gear Cover 1

Not Shown V3186 Transformer 110VAC-12VAC 1

Parts Breakdown

Front Cover and Drive Assembly
