Sentry VREL Control Valve 9
Figure 3. 6-02302E – Valve Handle & Rod Assembly
6-02303A
Rod & Nut
6-02302A
Valve Handle Assembly
Figure 4. VREL
4" [102mm]
REF.
14 1/8" [359mm]
REF.
19 9/16" [497mm]
REF.
Alignment Pin
Body Nut
Panel Lock Nut
1/4" max panel thk
12 7/16"
Removal Clearance Required
4 5/16"
5 5/16"
15/16"
Ø 5/16"
Ø 1 1/4"
Plain End
37˚ Fitting Socket Weld
Panel Cutout
