3
WARNING!
Before making holes in walls or oors. Ensure that the location for wall penetration
allows for a hole to be made and that the piping meets construction regulations. Keep
in mind that the wall may conceal, for example: electrical wiring,piping,waterproong,
load-bearing construction.
IMPORTANT! Alwaysconsult your local environmental ofce to nd out what rules apply in your munici-
pality. Alwaysfollow local regulations. Please view our installation video at www.ecoo.com.au.
To make sure the toilet stays odour free, the fan in the toiletshould always be running for it to ventilate
and receive fresh air to ventilate out. To achieve this, the followingis required:
1. No other fan/ventilation system may affect the same room.
2. Ensure that fresh air from the outside enters the room. The air entry point should be as close to the
toilet as possible.
Useful tools
Hole sizes:
51mm (1,5”)- ventilation
33mm (1 3/8”)- urine outlet
