Installation without visible pipes
The included 90-degree bend is used to lay pipes backwards or to the side. The bend is placed as shown
below and turned in the rearward direction. The bend can be difcult to get in place. Vaseline or a similar
product may be used to facilitate the assembly.
The supplied ventilation pipe is then connected to the 90-degree bend. The pipe is 40 cm (15,7”)long, which
generally is enough to reach through an outer wall. If additional pipes are needed to direct the air out of
the house, the Separett ventilation kit (art. no. 1344) is recommended for Tiny. It includes 4 meters of piping
and bends to ensure a simple extended installation. These can also be used to extend the pipingonto the
facade of the house. Please note that as short an installation as possible is recommended to guarantee full
function throughout the year.
If the installation is to go through the
oor, the pipe should be connected
directly to the toilet, as shown below.
The picture belowshows what a con-
nection to Tiny can look like.
