Seres OL TOPAZ - Hydraulic Requirements

2
Environmental conditions
Temperature : 5°C to 40°C
Relative humidity : 10% to 80%
Pollution level : 2
Installation category : II
Altitude : max 2000m
Installation precautions : sheltered from bad weather, humidity, corrosive
surrounding and dust
Do not use this equipment in hazardous area (presence of flammable liquids,
gases…), it could represent safety hazard.
Physical/Electrical characteristics
PRODUCT
TOPAZ / CRISTAL / ONYX / SERES 2000E
Dim : w*h*d (mm*mm*mm)
480*750*320
Fixation
Wall mounted with 4 screw-bolts M8 (PC panel at operator eye level to
simplify maintenance)
Power supply / section
100~240 V, 50/60 Hz, max 3 mm², unscrew right side to connect cable
(cable gland 7.5 to 13 mm and 13 to 19mm)
Power consumption
Typically 150 VA - Maximum 300 VA
Input/Output wire section
Max 1.5 mm²
Protection
IP55
Hydraulic requirements
Sample clean and clear
Particles<100µm, filtered if necessary
Inlet (sample/dilution water) : optimal flow /
max pressure / connection
4 to 40 l/h ; <3 bars ; ¼’ female BSP
Overflow : 8*12mm flexible tube
Sample temperature
< measuring temperature (depend on method)
Waste outlet / connection
Free not closed ; 12*14 mm flexible tube
Air input (on demand) / connection
Blowing of the apparatus (filtered, clean and dry air, min
flow of 200l/h) ; 6 mm tube
