STEP
STEP 33
STEP 34
33.1
35.1
33.2
1) Fill the shock body with
shock absorber oil. Check
the oil CST value in the setup
sheet.
2) Bleeding: Let the oil settle
and allow the air to escape.
Close the shock slowly.
Important: do not crossthread!
built-in bleed channel.
Tighten carefully until the bottom
half sits against the shock body.
3x5x1
35.2
23
STEP 32
3x5x1
2
1
Insert the o-ring
inside the spring
collar.
