Serpent SRX2 GEN3 CARPET - Page 8

8
STEp 10 STEp 11
CASTERBLOCKINSERTS CHART
M2.3x4
3x24
3x33
1
2
3
1
1
2
3
M3x14
M2.3x4
M3x14
Front default caster angle is
25º using the 0º default insert.
You can add or remove caster
using the different inserts
included in the kit.
It is possible to adjust the
caster angle from 20º to 30º
in 2.5º steps according the
the chart shown below:
+ Caster
- Caster
4
3x33
M3x6
M3x6
baG 4
M3x3
M3x3
M3x3
