Serpent SRX2 GEN3 CARPET - Front Assembly; Steering Block Assembly

7
fRONT aSSEmbly
STEp 9STEp 8
M3x14
M3x16
M3x16
M3x10
M3x12
1mm
1mm
M3x12
M3x4
5x10x4
5x13x4
1
1
1
2
4
3
2
2
2
3
STEERINGARMSCHART
LESS
ACKERMANN
MORE
ACKERMANN
STEERINGBLOCKASSEMBLY
9.1 9.2
Place the caster shims and the bushings
in the steering block first. Then slide the
assembly onto the casterblock.
M3x16 M3x10
M3x12
M3x4
1
3
4
M3x8
M3x8
5x10x4
M3x14
baG 3
5x13x4
