12
With the bases in their desired location, slightly loosen both legs
to allow the strap to t on the leg bolt, between the leg washer
and frame.
Slide side (a) of the connecting strap onto leg bolt. Swing the
strap and connect side (b) to the leg bolt. Secure the strap by
shifting to the left.
Re-tighten legs. Do not over tighten. Use the remaining strap
and repeat on other end of the base.
STEP 2
STEP 1
STEP 3
connecting strap (optional)
a
b
If any split setup is being installed (excluding Divided King), plastic connecting straps are provided
(one per base) to secure the bases together. Use both straps to secure the head and foot portions together.
