6 of 8
Carefully lift and turn assembled unit onto its legs. A flat configuration of the sofa
indicates that it is in bed position (refer Operating Your Unit on page 7).
3 of 8
ASSEMBLY INSTRUCTIONS
CAUTION:
At least two adults are required to safely complete performing this task.
Other lifting attempts may risk back injury due to large and heavy part(s).
Carefully place sofa body unit on a clean flat surface with bottom side facing up.
Align front leg as shown below and secure a long bolt and washer each using the
provided Allen key.
Secure support leg onto pre-assembled center metal rail with two short bolts until
firmly tight.
