(10) x 4
(7)
Attach Seat Plate (7) onto the bottom of Seat Cushion (6) (with front of seat plate
facing front of seat cushion) by using M6X20MM Screws (10) in the holes of Seat
Plate (7) and tighten screws with Allen Key (12).
8
