Sertain S4540 - Audible Error Indicators

DO NOT USE CHAIR UNTIL YOU HAVE FULLY READ THE INSTRUCTIONS
6.0 AUDIBLE ERROR INDICATORS - BUZZER
Position Lost:
200 ms pause
200 ms beep
50 ms pause
50 ms beep
500 ms pause
50 ms beep
200 ms pause
50 ms beep
1000 ms pause
50 ms beep
POSITION LOST on an actuator is indicated via an intermittent beep 200msec ON / 200msec OFF. Try the RESET/
INITIALISATION procedure (refer to 5.7.1 and 5.7.2 on Page 21) and then in turn run all functions. If problem persists,
locate faulty actuator or cable and replace.
FATAL ERROR is indicated via an intermittent beep 50msec ON / 500msec OFF. Try the RESET/INITIALISATION
procedure (refer to 5.7.1 and 5.7.2 on Page 21) and then in turn, run all functions. If problem persists, locate faulty
actuator/cable and replace. This could also be caused by CB6/CU20 problems, replace as required.
Overload:
Manual Mode:
Error (5 beeps):
Fatal/System Error:
Constant beep
Technical Data
