DO NOT USE CHAIR UNTIL YOU HAVE FULLY READ THE INSTRUCTIONS

3.5 Swing Away Head Wings - (Models with this feature)

Make sure client/patient and carer are safe and client is positioned

safely.

Refer to Figure 5 - While applying light pressure on head wing at ‘C’

lift at ‘D’ and swing the wing outwards and relocate into the desired

position. To return to the original position reverse this procedure.

Assess need for brakes to be engaged.

3.6.1 Removable 2- Position Armrest - (Models with this

feature)

First make sure that the brakes are applied and client/patient and

carer are safe and client is positioned safely, including limbs, clothing,

etc.

To operate 2 position feature – refer to Figure 6.1 - pull and hold the

white release knob found near the front of the arm (down at the pivot

bracket), and rotate the arm away from the chair. Release the knob

and the pin will drop into the 2nd position (23°) as the arm is rotated.

To return to the original (standard) position, reverse this process.

Operating Instructions

Figure 5

Figure 6.1
