SERVIS W712F2W - Front View; Rear View; Your Washing Machine

05 06
T: 0800 0124 382 T: 0800 0124 382
YOUR WASHING MACHINE
1
4
FRONT VIEW REAR VIEW
Detergent drawer
2
Control panel
Door handle
5
Pump filter cover
Drain hose
1
2
Cold water
inlet
Figure 2
Figure 3
1
Detergent drawer; Allows you to insert detergent, fabric conditioner and starch.
2
Programme dial; Allows you to select the programme for your wash.
3
Control panel; Allows you to configure the required settings for your wash.
4
Door handle; Provides you with access to the drum.
5
Pump filter cover; Provides access to the pump filter for maintenance purposes.
1
Drain hose; Provides an outlet for the dirty water from your Washing Machine.
2
Cold water inlet; Connects your Washing Machine to your cold water supply.
2
Transit bolts; Remove before first use of your Washing Machine (refer to page 9).
3
Programme dial
3
Transit bolts
3
