YOUR WASHING MACHINE
1
3
FRONT VIEW REAR VIEW
Detergent drawer
2
Control panel
Door
handle
4
Pump filter cover
Drain hose
1
2
Cold water
inlet
Figure 2
Figure 3
1
Detergent drawer; Allows you to insert detergent, fabric conditioner and starch.
2
Control panel; Allows you to configure the required settings for your wash.
3
Door handle; Provides you with access to the drum.
4
Pump filter cover; Provides access to the pump filter for maintenance purposes.
1
Drain hose; Provides an outlet for the dirty water from your Washing Machine.
2
Cold water inlet; Connects your Washing Machine to your cold water supply.
