Servodan 41-302 - Page 2

2(13)
L
1
N SL
L
1
N SL
60 mm
Fig. 5
L N SL
L
N
SL
41-302 - Master
PIR
L N SL
41-302 - Slave
PIR
ON
Factory settings
OFF
A) LUX - Test mode
B) PIR - Test mode
C) LED ON
D) Max. sensitivity
D) High sensitivity
D) Low sensitivity
D) Min. sensitivity
1 2 3 4
TIME
LUX
1
2
3
4
LUX
TIME
Min
Max
1
min
15min
30min
Fig. 6
Fig. 7 Fig. 8
1. Press down on the lightgate.
2. Position the new lightblocker in
the cover and press it into the hole.
Fig. 10Fig. 9
L N SL
L
N
SL
41-302 - Master
PIR
L N SL
41-302 - Slave
PIR
Push-
button
(230V)
TIME
LUX
1
2
3
4
3. Adjust LUX to max
