5. Maintenance.
Make sure that the lens is kept clean and dry. The
lens can be cleaned with a slightly damp cloth.
Contact a qualified electrician in the event of faults
or breakdowns apart from the normal user settings
LUX, TIME and SENSITIVITY.
6. Technical specifications.
Input:
Power supply .............................. 230V AC ±10% 50Hz
Power consumption ................... approx. 1 W
Output:
Relay contact ............................. NO, μ 10 A
Load
Incandescent lamps ............... 2300 W
Fluorescent tubes
(not compensated) ................. 1200 VA
Max. capacity ......................... 140 μF
Max. starting current .............. 80 A / 20 ms
Performance:
Lux range ................................... 10…1000 Lux
Hysteresis .................................. +10%
Off delay .................................... 1-30 min.
Sensitivity ................................... Selected manually
Activation indicator on/off ......... Selected manually
Test modes ................................. Selected manually
Protection ................................... IP 20
Cable input .................................. 2 x Ø12 mm
Installation height ....................... 2,5 - 3,4 m, see Fig. 1
Ambient temperature. ................ -5°C…+50°C
Approval
CE according to ......................... EN 60669-2-1
