Servotronix CDHD2 - Page 18

CDHD2
18 Operator Panel (HMI)
Parameter
Description
Code
INDEXDURATE
Simulated Encoder Index Pulse Duration
P2032
Secondary Feedback
Starting at index 2100
HWPEXT
Hardware Position External
P2100
HWPEXTCNTRLR
Hardware Position External (FPGA)
P2101
HWPEXTMACHN
Hardware Position External (DSP)
P2102
SFB
Secondary Feedback
P2103
SFBMODE
Secondary Feedback Mode
P2107
SFBOFFSET
Secondary Feedback Offset
P2108
SFBTYPE
Secondary Feedback Type
P2113
LMUNITSDEN
Motor to Load Scaling Denominator
P2114
LMUNITSNUM
Motor to Load Scaling Numerator
P2115
Motor
Starting at index 3000
MOTORNAME
Motor Name
P3000
MOTORTYPE
Motor Type
P3001
MICONT
Motor Continuous Current
P3002
MIPEAK
Motor Peak Current
P3003
MSPEED
Motor Maximum Speed
P3004
MPOLES
Motor Poles
P3005
MPITCH
Motor Pitch
P3006
MKT
Torque Constant
P 3007
MKF
Torque Constant for Linear Motor
P3008
ML
Motor Inductance
P3009
MR
Motor Resistance
P3010
MOTORCOMMTYPE
Motor Commutation Type
P3011
MFOLD
Motor Foldback Status
P3012
MFOLDD
Motor Foldback Delay Time
P3013
MFOLDDIS
Motor Foldback Disable
P3014
MFOLDF
Motor Foldback Factor
P3015
MFOLDR
Motor Foldback Recovery Time
P3016
MFOLDT
Motor Foldback Time Constant
P3017
MIFOLD
Motor Foldback Current
P3018
MIFOLDFTHRESH
Motor Foldback Fault Threshold
P3019
MTPMODE
Electronic Motor Nameplate Mode
P3020
Digital I/Os
Starting at index 4000
INMODE 1
Input Mode (input 1)
P4000
INMODE 2
Input Mode (input 2)
P4001
INMODE 3
Input Mode (input 3)
P4002
INMODE 4
Input Mode (input 4)
P4003
