Parameter
Description
Code
OUTBRAKEINV
Manual Brake by Output Inverse
P4042
OUTBRAKEMODE
Manual Brake by Output Mode
P4043
OUTFLTLVL
Force Digital Output State on Fault
P4044
OUTILVL1
Current 1 Digital Output Definition
P4045
OUTILVL2
Current 2 Digital Output Definition
P4046
OUTINV
Position 1 Digital Output Definition
P4047
OUTPLVL2
Position 2 Digital Output Definition
P4048
OUTVLVL1
Velocity 1 Digital Output Definition
P4049
OUTVLVL2
Velocity 2 Digital Output Definition
P4050
RELAY
Fault Relay Status
P4051
RELAYMODE
Fault Relay Mode
P4052
Analog I/Os
Starting at index 4200
ANIN1DB
Analog Input 1 Deadband
P4200
ANIN1FILTAFF
Analog Input 1 MSQ 2nd Deriv FF
P4201
ANIN1FILTIN
Analog Input 1 Before MSQ Filter
P4202
ANIN1FILTMODE
Analog Input 1 MSQ Filter
P4203
ANIN1FILTT1
Analog Input 1 MSQ Filter Depth
P4204
ANIN1FILTT2
Analog Input 1 MSQ 1st 2nd Deriv
P4205
ANIN1FILTVELFF
Analog Input 1 MSQ 1st Deriv FF
P4206
ANIN1LPFHZ
Analog Input 1 Filter
P4207
ANIN1OFFSET
Analog Input 1 Offset
P4208
ANIN2DB
Analog Input 2 Deadband
P4209
ANIN2ISCALE
Analog Input 2 Current Scaling
P4210
ANIN2LPFHZ
Analog Input 2 Filter
P4211
ANIN2MODE
Analog Input 2 Mode
P4212
ANIN2OFFSET
Analog Input 2 Offset
P4213
ANIN2USER
Analog Input 2 Voltage User Units
P4214
ANIN2USERDEN
ANIN2USER Conversion Denominator
P4215
ANIN2USERNUM
ANIN2USER Conversion Numerator
P4216
ANIN2USEROFFSET
ANIN2USER Conversion Offset
P4217
ANIN2ZERO
Analog Input 2 Zero Command
P4218
ANOUT
Analog Output Value
P4219
ANOUTCMD
Analog Output Command
P4220
ANOUTISCALE
Analog Output Current Scaling
P4221
ANOUTLIM
Analog Output Voltage Limit
P4222
ANOUTMODE
Analog Output Mode
P4223
ANOUTVSCALE
Analog Output Velocity Scaling
P4224
