TROUBLESHOOTING
FAULT CAUSE SOLUTION
Water drips out
when moving unit
Unit was unplugged before
purging was complete.
Purge unit before moving. See PURGE in Control Panel in-
structions, p. 6. At the end of the job, see “At the End of the
Unit does not
operate
Unit not switched on.
No power to machine.
Plug in unit; check power cord connection at wall outlet and at
Unit operating,
but room not dry
Not enough time to dry.
Poor air movement in room.
Excessive moist air infiltration.
Allow more time for drying.
Increase air movement with air movers.
Seal off area to reduce infiltration.
Unit collects too
little water
Room air is dry.
Room temperature is too low.
Filter is clogged.
Coils are clogged.
Confirm humidity level with hygrometer.
Increase room temperature.
Check filter. Clean or replace as necessary.
Check coils. Clean as necessary.
If the problem you are experiencing is not listed here, call your local distributor or contact
our Service Department toll-free at 800-932-3030 for further assistance.
SPECIFICATIONS
Name
Revolution LGR Dehumidifier
Model F413-115V
Dimensions (W × H × D)
12.5 × 17.6 × 21.5 in.
31.8 × 44.7 × 130.8 cm
Weight (w/ cord & hose) 65 lbs. | 29.5 kg
Amps 6.2 amps at 80°F/60% RH
Air movement 121–180 CFM | 3.43–5.1 CMM
Water removal
80 pts/day | 38 L/day
at 80°F/60% RH (AHAM)
134 pts/day | 63 L/day
at 90°F/90% RH
Operating temperature range 33–100°F |1–38°C
Safety ETL certified to CSA Standards
Specifications are subject to change without notice. Some values
PARTS INCLUDED
40 ft. (12 m) of drain hose with quick-connect fitting.
25 ft. (7.6 m) detachable power cord.
3M™ HAF High Air Flow filter
OPTIONAL
Duct Attachment Kit (F530)
FILTERS FOR REORDER
3M™ HAF High Air Flow filter F372 (24 pack)
ADDITIONAL PRODUCT INFORMATION and current
documentation is available at http://Revo.DriEaz.com.
FOR PARTS AND SERVICE CONTACT SERVPRO
RMA DEPARTMENT.
07-01897D #613 (F413-SP) Warranty 07-00420 12 Dri-Eaz Products, Inc.
