SET SET-2010 - Technical and Environmental Specifications

10 of 10
www.smart-e-tech.com
SET-2010
Technical Description
Issue 02 13/04/2022
Technical Data
Property
Condition
Value
Comment
Update Time
10 ms
SLSC Commit CMD
duration
Max. Initial contact
Resistance
J1 -> XJ2
J2 -> XJ2
J1 -> J2
500 mΩ
Max. Electrical Lifetime
Expected
1 A, 30 Vdc resistive
Min 10^5 operations
Min. Electrical Lifetime
Expected
1.5 A, 30 Vdc resistive
Min 10^4 operations
Bandwidth
-3 dB, 50 Ω Termination
≤ 20 MHz
Physicals Characteristics
Property
Condition
Value
Comment
Module Dimensions
Excluding ejector
144.32 mm x 30.48 mm x
302 mm (H x W x D)
Standard SLSC card size
Front Panel Connector
2x female DB -44 high-
density D-Sub with 4-40
UNC screw lock
For mating connectors and
cables, see below
RTI Connector
2 mm hard metric per IEC
61076-101
Any RTI marked
Environmental
Property
Condition
Value
Comment
Operating Humidity
Relative, non-condensing
10%-90%
Storage Humidity
Relative, non-condensing
5%-95%
Operating temperature
Forced-air cooling from
chassis
0°C - 40°C
Storage Temperature
-40°C - 85°C
Maximum Altitude
2000 m
