Parts List
Please make sure you have all the parts on this list.
If you’re missing parts, contact us for replacements at
(800) 323-5565 or send an email to Support@SevilleClassics.com
Assembly Instrucons
STEP 1. Connect Side Frames
Make sure channels on each
SIDE FRAME (A) face each other.
Fit a WASHER (H) between SIDE
FRAME (A) and CROSSBAR (B).
Curved side of washer MUST face
side frame. Flat side of washer
MUST face crossbar.
Insert SCREW (G) through outer bolt
holes on a SIDE FRAME (A), WASHER
(H) and into CROSSBAR (B).
Tighten with screwdriver unl snug.
Repeat for remaining screw holes.
A. Side frame (2)
B. Crossbar (4)
C. Shelf (1)
D. Drawer (6)
E. Caster (2)
F. Locking caster (2)
G. Screws (8)
H. Washer (8)
I. Wrench (1)
STEP 2. Install Shelf and Casters
Clip SHELF (C) on to top crossbars.
STEP 3. Screw CASTERS (E,F) into
base of poles with WRENCH (I).
J. Label holder (6)
Required Tools (not included)
Screwdriver
