INFLATABLE BOATS
®
GRAB LINE INSTALLATION:
IMPORTANT: To properly install the inatable boat’s grab line, rst
inate the boat. Feed the grab line through the eyelets on each of the
rope holders. Then tie the two loose ends in a square knot at the rear
of the boat.
The assembled oar is to be inserted into the oar locks from the
outside of the boat. The oar retainer ring is then placed onto the top
half of the assembled oar, from the inside of the boat, to prevent the
oar from sliding into the water (see below).
OAR ASSEMBLY:
(for models with oar included)
Join the two shafts together by screwing them together into the
coupler. Attach the blade to the shafts by screwing in into the bottom
of the shaft.
Replacement Part #2000004151
Square Knot
Retainer
Ring
Coupler
Shaft Shaft
Blade
8
