3.1.4 Parameter setting
The following table shows the setting options and the effects of the individual parameters. A
parameter can be selected via the menu selection
(see point 3.1.1).
For reasons of safety, the modification mode for the parameters can
only be enabled in the ‘Stop’- operation (key
).
1st line on display
2nd line on display
(set value)
Signification
base load OFF Pump off ≤ Pump on Stop level pump
Modifications only during Stop-
operation!
base load ON Start level pump
Modifications only during Stop-
operation!
high water
(High water HW)
Peak load on < HW
And
HW ≤ final value of level
sensor
Flooding- alarm- level
Additionally, this level is constantly
evaluated on the input for the
floating switch HW, independent
from the selected level transmitter.
Thereby, if necessary, 2 different
HV-levels can be realised with 2
different transmitters.
Modification only possible in Stop-
mode !
run-time
(Run-time change after)
is deactivated
until 300 sec.
At transgression of the adjusted time the
pump is stopped shortly.
‘DEACTIVATED’ effects that the pump run is
not stopped abruptly.
This function eliminates potential
accumulations of air in the pump.
Here unto a time above the normal pump-
down time has to be adjusted. A switch
occurs if the requested pump has not
pumped down under the switch-on point
within the adjusted time. After 3 consecutive
the error ‘TIME’ occurs.
