Description SG-239 SG-237 SG-230 SG-231
SG-235
HF Frequency Range 1.8 - 30MHz 1.8 - 60MHz 1.6 - 30MHz 1 - 60MHz 1.8 - 30MHz
Power Input Range (PEP 1.5 - 200 3-100 3-200 3-100 3-500
Cont. CW Power (watts) 80 40 80 60 200
Input Impedance Range 45-55 45-55 45-55 45-55 45-55
VSWR (Typical) <2:1 <2:1 <2:1 <1.4:1 <2:1
DC Input Requirement 13.8 13.6 13.6 13.6 13.6
DC Op. Range (VDC) 10 to 18.5 10 to 18 10 to 18 10 to 18 10 to 18
Input Current (avg. amps) 0.23 0.3 0.9 0.5 1.4
Random Set Times (sec) <2 <4 <2 <4 <2
Recurrent Set Times (ms) <10 <10 <10 <10 <10
Non-Volatile Memory 170 170 170 170 170
Total combinations using 1/8 million half million half million four million half million
Antenna Length operating 40 feet min. 8 feet min. 8 feet min. 8 feet min. 23 feet min.
Antenna Length operating
from the lowest frequency
100 feet min. 28 feet min. 23 feet min. 23 feet min. 150 feet min.
Elements configuration Pi & L Pi & L Pi & L Pi & L Pi & L
Input Capacitance min. 50pf 50pf 100pf 50pf 100pf
Input Capacitance max. 3150pf 6400pf 6400pf 6400pf 6400pf
Inductance minimum 0.125µH 0.125µH 0.25µH 0.125µH 0.125µH
Inductance maximum 15.875µH 32µH 64µH 64µH 32µH
Output Capacitance min 50pf 12.5pf 25pf 12.5pf 12.5pf
Output Capacitance max 740pf 200pf 800pf 400pf 400pf
Installation Any position Any position Any position Any position Any position
Operating Temperature -35C to +70C -35C to +70C -35C to +70C -35C to +70C -35C to +70C
Environmental None Waterproof at immer- Waterproof at immer- Waterproof at immersion of Waterproof at immersion of
Size Overall 7.5”Dx6”Wx1.85” H
(19cmx15cmx5cm)
6”Dx7”Wx1.5”H
(23cmx18cmx4cm)
16”Dx12”Wx3”H
(41cmx31cmx8cm)
11.5”Dx9.5”Wx1.7”H
(29cmx24cmx4cm)
16”Dx12”Wx3”H
(41cmx31cmx8cm)
Weight 2 lbs. (0.75kg) <2 lbs. (<0.75kg) 8 lbs. (3.5kg) 3.8 lbs. (1.6kg) 8 lbs. (3.5kg)
Case Construction Aluminum case Plastic ABS
Waterproof case
Plastic ABS
Waterproof case
Plastic ABS
Waterproof case
Plastic ABS
Waterproof case
Cable(s) (NOTE: All
couplers require RF and
12 volt lines only. SGC
cables are required for
additional features only.)
Terminals SGC cable, 9 feet
coaxial and two power
wire input, and RMT
tune and SmartLock
wire.
SGC cable, 9 ft coaxial
and two power wire
input, and RMT tune
and SmartLock wire
10 feet RG-58 power cable,
10 feet RG-58 coax cable
with PL259 connectors
SGC cable, 9 ft coaxial and
two power wire input, and
RMT tune and SmartLock
wire.
