Specifications SG-239
HF Frequency Range: 1.8-30 MHz
Power Input Range: 1.5-200 watts (PEP)
Or CW duty cycle 40%
Number of channels: unlimited
Revolving memory bins: 165 TX; 5 RX
Input Impedance Range: .2-5000 ohms
VSWR: (Typical) Typically less than 2:1
DC Input Requirement: +13.8 VDC (nominal)
DC Operating Range: +10 to 18.5 VDC
Input Current: Average: 230 milliamps
Random set time: Typical: less than 2 seconds
Recurrent set time: Typical: less than 10 milliseconds
Antenna Length: Minimum length of 9 ft. - 7 to 30 MHz
Minimum length of 40 ft.-3 to 30 MHz
Minimum length of 100 ft. - 1.8-30 MHz
Installation: Any position
Operating Temperature: -35° to +70°C
Size: 7.5”L x 6”W x 1.85”H
(19cm x 15cm x 4.5cm)
Weight: 2 pounds
Case Construction: Irradiated aluminum case
Control Cable Standard coaxial and 2 wires for DC plus 2
(not supplied) wires for optional SmartLock gauge 14-18
Antenna types: 1. Whip
2. Backstay (marine, sail)
3. Dipole centerfed
4. Dipole with feedline
5. Loop (small) 2x2 multi turn
6. Loop (large) 10 ft. and up single turn
7. Longwire
8. Ladder feed
Specifications subject to change without notice.
SG-239 Manual
page 5
