PAGE 45
13. TECHNICAL SPECIFICATIONS
Power Unit
Displacement 58cc
Fuel Mixture Petrol 25 : Two Stroke Oil 1
Fuel tank capacity 550 cm3
Oil tank capacity 260 cm3
Carburettor Diaphragm type
Ignition system Pointless (CDI)
Spark plug L D L7T
Oil feeding system Automatic pump
Sprocket 7T x 0.325”
Dimensions 390 L x 250 W x 290 H (mm)
Dry weight 5.8 kg
Cutting Head
Guide bar type Sprocket nose
Guide bar size 18” (450mm), 20” (500mm)
Saw chain pitch 0.325”, 8.26mm
Saw chain gauge 0.058”, 1.27mm
Power 2.3/8,500 (kw/min)
Max speed 12,000 rpm
Idle speed 3000 rpm
