SGS EC2000 - Page 4

ITEM DESCRIPTION QTY
H1 SPRING WASHER 8 24
H2 NUT M8 16
H3 BOLT M8X20 16
H4 BOLT M8X12 8
H5 BOLT M14X95 2
H6 WASHER 14 3
H7 NUT M14 3
H8 SPRING WASHER 16 2
H9 NUT M16 6
H10 BOLT M16X100 1
H11 BOLT M16X115 2
H12 BOLT M18X125 2
H13 SPRING WASHER 18
2
H14
NUT M18 3
H15 PIN 18X110 2
H16 SPLIT PIN 2
H17 BOLT M16X90 2
H18 WASHER 16 4
H19 BOLT M18X110 1
H20 WASHER 18 1
H21 BOLT M16X75 1
H22 BOLT M14X75 1
WWW.SGS-ENGINEERING.COM
PAGE 4
