SGS EC2000 - Page 6

ITEM DESCRIPTION QTY
1 VALVE BLOCK 1
2 COPPER WASHER 1
3 CYLINDER 1
4 O-RING 1
5 O-RING RETAINER 1
6 RAM 1
7 TOP NUT 1
8 O-RING 1
9 SEALING GASKET 1
10 OIL TANK 1
11 OIL PLUG 1
12 SEAL RING 1
13 TUBE 1
14 BOLT 1
15 SCREW 2
16 BALL 1
17 SEAL RING 1
18 RELEASE SPINDLE 1
19 BALL 1
20 COPPER WASHER 1
21 PUMP CYLINDER 1
22 O-RING 1
23 BACK UP RING 1
24 PLUNGER 1
25 PUMP LINK 1
26 HANDLE 1
27 HANDLE SOCKET 1
28 SHAFT 2
29 COTTER PIN 2
FOR YOUR SAFETY
PLEASE READ THESE INSTRUCTIONS CAREFULLY
AND RETAIN THEM FOR FUTURE USE.
