PAGE 38
PARTS DIAGRAM
PARTS LIST
No Part name Code Qty No Part name Code Qty
1
Screw M10 900802
1 30 Gasket ø6xø12x1.5
904320
1
2
Cover 904292
1 31 Lock net
904321
1
3
Plate 904293
1 32 Quick connect
904322
1
4
Blade sheath 904294
1 33 Bolt M6x30
903949
1
5
3 teeth blade SSTBLADE1
1 34 Bolt M4x16
904324
1
6
Plate 904296
1 35 Bolt M5x10
901696
1
7
Bolt M5x10 901696
3 36 Location plate
904326
1
8
Cover 904298
1 37 Spring
904327
1
9
Snap ring ø32 904299
1 38 Connector
904328
1
10
Bearing 6002 904300
1 39 Throttle assembly
904329
1
11
Spline shaft 904301
1 40 Bolt M6x20
904201
4
12
Driven gear 904302
1 41 Upper plate branket
904331
1
13
Bearing 6000 904619
3 42 Handle bracket
904332
1
14
Gearcase 904304
1 43 Rubber
904333
2
15
Grease fitting 904305
1 44 Bracket Seat
904334
1
16
Bolt M5x25 901958
1 45 Oil Bearing
904335
6
17
Bolt M5x12 904074
1 46 Drive Shaft
904336
2
18
Driving Gear 904308
1 47 Pipe
904337
1
19
Ring ø10 904309
2 48 Harness hanger
904338
1
20
Snap ring ø26 904310
3 49 Connection Tube
904339
1
21
Grease fitting 904311
1 50 Snap ring ø45
904340
1
22
Screw ST4x8 904312
3 51 Anti-vibration rubber
904341
1
23
Small Blade 904313
1 52 Bolt M6x30
903949
4
24
Shield Rim 904314
1 53 Housing
904343
1
25
Guard 904315
1 54 Ring ø15
904344
1
26 Guard Bracket
904316
1 55 Bearing 6202
904004
1
27 Bolt M6x25
902554
4 56 Snap ring ø35
904346
1
28 Nut M6
904048
1 57 Drum
904347
1
29 Nut M4
904178
1 58 Engine
904348
1
WWW.SGS-ENGINEERING.COM
CALL FOR ASSISTANCE: 01332 576 850
