Questions and Answers

T
tclarkeAug 25, 2025
Why Shanghai Diesel Engine H Series Engine alternator refuses to charge?
- A
  Anthony DavisAug 25, 2025
  If the alternator in your Shanghai Diesel Engine Engine isn't charging or isn't charging adequately, it could be due to a few reasons. Check the instrument or indicator light and replace it if it has failed. Ensure that the battery connectors are clean and tight. Inspect the drive belt for slippage or tensioner failure, replacing the belt if necessary and checking the tensioner's spring performance. Also, make sure that all terminal connections of the alternator are tightened.
M
Michael Conway DVMAug 26, 2025
What to do if Shanghai Diesel Engine H Series starts, but will not keep running?
- L
  Laura BennettAug 26, 2025
  If your Shanghai Diesel Engine Engine starts but then stalls, consider these possible causes. First, ensure the engine is disengaged from the drive system. Next, check for air in the fuel system; tighten or replace any leaky fuel joints or pipes, and then prime the system. A blocked fuel filter or fuel suction pipe could also be the issue, so replace them if needed. Finally, verify that the fuel meets the required specifications and is of good quality; try running the engine with high-quality fuel from a temporary tank to rule out fuel issues.
T
Timothy BrooksAug 27, 2025
How to fix liable misfire or unsteady speed of Shanghai Diesel Engine?
- M
  Mindy SmithAug 28, 2025
  To address liable misfire or unsteady speed in your Shanghai Diesel Engine Engine, start by checking the fuel level in the tank and add fuel if it's low. Inspect the fuel system for air, tightening or replacing fuel joints and pipes as needed, then prime the system. Low fuel pressure could also be the cause, so check the fuel tank level and the pipe between the tank and the fuel transfer pump for leaks, deformation, bends, or blockages. Also, check for air. Tighten any leaking high-pressure fuel pipe connectors, and if necessary, replace them. Finally, verify that the injection pump timing is correct.
T
Thomas HuffAug 30, 2025
Why Shanghai Diesel Engine H Series has starting system fault?
- M
  Matthew SparksAug 30, 2025
  A starting system fault in your Shanghai Diesel Engine Engine may be caused by loose, open, or eroded terminals and connectors in the starting circuit or at the battery; clean and tighten all terminals and connectors. Insufficient battery output can also be a factor, so use a battery with sufficient output or add more batteries in parallel. Finally, the starting motor itself could be faulty, so you should check it.
C
Crystal MccormickAug 31, 2025
What causes diesel knock in Shanghai Diesel Engine?
- N
  Nicole PerezSep 1, 2025
  Diesel knock in your Shanghai Diesel Engine Engine can be attributed to several factors. Air in the fuel system is a common cause, so check for air, and tighten or replace fuel joints and pipes as needed, then prime the system. Poor quality fuel can also lead to diesel knock; use the fuel specified in the manual and test with high-quality fuel from a temporary tank. Incorrect injection pump timing is another potential cause.
K
Kelly MitchellSep 2, 2025
What causes Shanghai Diesel Engine H Series Engine to not reach rated speed with load?
- S
  Stephanie NelsonSep 3, 2025
  If your Shanghai Diesel Engine Engine can't reach its rated speed under load, the issue could be due to several reasons. The load might be too heavy, so try reducing it or shifting to a lower gear. There could be a mismatch between the drive system and the engine, so inspect the transmission gears. A faulty tachometer or speed sensor could also be the cause. Check the fuel filter and suction pipe for excessive resistance, and replace the fuel filter if necessary. A turbocharger fault or leakage in the intake system (check manifold, pipes, and intercooler connections) can also prevent the engine from reaching its rated speed. Finally, ensure the fuel meets the required specifications and is of good quality.
J
Jeffrey ScottSep 4, 2025
Why Shanghai Diesel Engine liable misfire at low speed?
- K
  Kimberly VasquezSep 5, 2025
  If your Shanghai Diesel Engine Engine experiences liable misfire at low speed, it might be due to low fuel level in the tank, so add fuel. Another potential cause is air in the low-pressure fuel pipeline. Check the pipeline for air, and tighten or replace joints or pipes if necessary, then prime the system.
K
kingjacobSep 6, 2025
How to solve excessive vibration of Shanghai Diesel Engine?
- M
  Michael MedinaSep 6, 2025
  To address excessive vibration in your Shanghai Diesel Engine Engine, start by checking for loose pulley or vibrator bolts or nuts and tighten them. If that doesn't resolve the issue, loosen or remove the fan belts and briefly operate the engine at the vibration-inducing speed. If the vibration disappears, replace the fan assembly. Also, inspect the fan and accessories for damage, replacing any faulty parts. Finally, check the vibration damper for damage and replace it if necessary.
N
Natasha RobinsonSep 9, 2025
What causes Shanghai Diesel Engine Engine will not stop?
- D
  Desiree VangSep 9, 2025
  If your Shanghai Diesel Engine Engine won't stop, several potential causes exist. The electric key switch might be faulty. The engine could be inhaling fuel mist, so check the intake manifold and isolate the source. An external power supply might be connected, so ensure none is connected to the vehicle's power supply circuit. Lastly, oil could be leaking in the turbocharger due to a poor seal; check the compressor outlet and intake pipe for oil traces.
T
Taylor WolfeSep 12, 2025
What causes poor acceleration in Shanghai Diesel Engine?
- L
  Lisa WattsSep 12, 2025
  Poor acceleration in your Shanghai Diesel Engine Engine can be caused by several factors. Overloaded accessories can create too much resistance, so check the cooling fan, air conditioner, and vehicle braking system. A restricted accelerator pedal or throttle lever can also limit acceleration, so check for any obstructions. Additionally, check the intake manifold, intake pipe, intercooler, and their pipelines for leaks. Finally, a blocked intake or exhaust system can hinder performance, so check their resistances.

Summary

告诫

产品报修技术咨询投诉与建议

Provides contact information and procedures for product support and feedback.

1 引言

1.1 致用户和操作者

Welcomes the user, introduces the H series diesel engine, and advises reading the manual.

1.2 使用范围

Specifies the applicability of the manual to all H series electronic control diesel engines.

1.3 用户反映产品质量情况须知

Details information required for reporting quality issues and facilitating analysis.

1.4 产品售后服务承诺

Outlines the 24-hour service commitment and hotline for support.

1.5 安全须知

Provides essential safety guidelines and warnings for operating and servicing the engine.

1.6 柴油机使用注意事项

Lists important operational precautions to prevent engine malfunction or damage.

1.7 柴油机上的警示标志

Highlights the importance of adhering to warning labels on the diesel engine.

2 柴油机概况

2.1 柴油机外形图

Illustrates the external components of the SC4H and SC7H diesel engines.

2.2 柴油机型号识别

Explains the meaning and structure of the diesel engine model designation.

2.3 柴油机铭牌

Describes the information found on the engine nameplate and its importance.

2.4 柴油机技术规格

Presents detailed technical parameters for various SC4H and SC7H engine models.

3 柴油机使用

3.1 燃油

Specifies fuel requirements and selection based on ambient temperature.

3.2 机油

Recommends engine oil specifications and viscosity grades for different temperatures.

3.3 冷却液

Advises on the use of dedicated SDEC organic coolant for optimal engine performance.

3.4 柴油机起动

Details pre-start checks and procedures for normal and low-temperature starting.

3.5 柴油机运行

Covers considerations for operating the diesel engine under various conditions.

3.6 柴油机停车

Explains the correct procedures for normal and emergency engine shutdown.

3.7 新柴油机或大修后柴油机的磨合

Outlines the process and importance of running in new or overhauled diesel engines.

4 柴油机保养

4.1 柴油机保养表

Provides a schedule for routine and periodic maintenance tasks based on mileage or hours.

4.2 柴油机保养记录

Offers a template for recording maintenance activities and dates.

4.3 柴油机保养内容及方法

Details the specific maintenance checks and procedures for various engine components.

5 ECU 整车功能和柴油机传感器

5.1 ECU 整车功能

Describes the functions of the ECU, including cruise control and speed limit.

5.2 传感器

Lists and explains the purpose of various sensors used in the diesel engine system.

6 柴油机故障排除指南

6.1 故障排除指南

Lists common fault modes, their causes, and troubleshooting steps.

6.2 柴油机故障码和闪码

Provides a table of diagnostic trouble codes (DTCs) with their descriptions and associated parameters.

7 柴油机停运后保存

7.1 短期停运保存

Details procedures for preserving the engine for short periods (1-3 months).

7.2 长期停运保存

Explains the preservation process for engines out of service for more than 3 months.

8 易损件清单

8.1 H 系列易损件清单

Lists common wear-and-tear parts for the H series diesel engines with part numbers.

9 随机附件清单
