Product description
GL09 is a simple & easy to use GSM Detector which sends SMS and calls you in case of alarm
events. Alarm event occurs in case of NO or NC ports changes.
9 Compatible with GA09 Device;
9 Wide power input voltage from DC5V to DC16V;
9 Only a local GSM SIM card is required to operate the device;
9 Each input port can be configured as NO or NC input type for alarm;
9 Each alarm input can be Armed and Disarmed independently;
9 “ RST ” line is used for programming or Reset the device;
9 DIP Switch when at ON Position,then unit will go to “Power-Save” status;
9 Measure the power input voltage and support Low voltage alert;
Wide power input range from DC5V to DC16V power input is the main features of the GL09
box,user can preset a Low voltage alert limit, then when the power input is dropped below the
voltage,then will send the alert SMS.This feature is very useful for battery operated situation.
When any S1 to S8 input is shorted to GND,then will trigger the alarm
