15
sharkclean.co.uk
14
1. Turn o the vacuum.
2. Using a coin, turn locks counterclockwise to open, then lift o cover to access brush-roll.
3. Clear airway of blockages.
4. Replace cover by sliding inserts into slots, then pressing down firmly on all sides before turning
locks clockwise to close. There will be an audible click once the locks are secured.
MAINTAINING YOUR VACUUM CLEANER
MAINTAINING THE FLOOR NOZZLE
If you run over a hard or sharp object or notice a noise change while vacuuming, check for blockages
or objects caught in the brush-roll.
Checking for Blockages in the Handheld Vacuum:
1. Turn o vacuum.
2. Remove the handheld vacuum from the wand.
3. Check all intake openings to the dust cup and
remove any debris or blockage.
Checking for Blockages in the Floor Nozzle:
1. Turn o vacuum.
2. Detach the wand.
3. Use the edge of a coin to open the three locks
on the bottom of the floor nozzle (see page 12).
4. Remove the cover and tilt back the neck of the
floor nozzle.
5. Check the opening and remove any debris or blockage.
6. Replace cover by firmly pressing down on all sides and
turn the locks counter clockwise.
CHECKING FOR BLOCKAGES
MAINTAINING YOUR VACUUM CLEANER
ANTI-HAIR WRAP FLOOR NOZZLE
Checking for Blockages in the Wand:
Flexology® Wand:
1. Turn o vacuum.
2. Remove the handheld vacuum and floor nozzle
from the wand.
3. Check the clog access on the Flexology® portion
of the wand by pinching the tabs on either side of
the hose and lifting the hose out for wand access.
4. Clear any debris and blockages.
NOTE: Anti Hair Wrap Technology removes hair from your brush-roll continuously as you vacuum. At times you may see
small amounts of hair around the brush-roll – simply continue vacuuming and the comb and suction will remove
the hair as you clean.
