Shark NV42 - Getting Started

4 TOLL FREE: 1-800-798-7398
Along with your upright unit, you
will find the following components:
a Vacuum Body
b Motorized Floor Brush
c Handle Assembly
d Super Stretch Hose
e Cleaning Wand
f Pet Upholstery Tool
g Cleaning Attachments
Getting Started
d
Your Shark Navigator
®
Upright
is easy to assemble:
1 Lay your vacuum body on a
level surface.
2 Slide the electrical connection
from the motorized floor brush
into the main body to click into
place.
3 Connect the hose from the
main body to the motorized
floor brush; push with a slight
turning motion to create a snug
fit.
4 Slide the handle assembly
into the upright unit aligning
the hose hook on the handle
assembly with the power cord
hooks on the back of the unit.
5 Secure the handle assembly in
place with included nut/bolt
(shipped attached to handle
assembly).
6 Place the vacuum in the upright
position.
7 Store the Crevice Tool, Dusting
Brush and Cleaning Wand on
the unit.
a c e*
g
b
f
4
5
3
2
7
