11
C
D
A
A
B E
SUN VISOR
TEXTILE PARTS - REMOVAL
REMOVAL
- Turn your helmet over.
- Separate the two parts of the chin strap.
- Remove the neck pad by holding one of its sides.
Pull out the end and then detach its rear section (Fig.
A).
- Unclip the two cheek pads (Fig. B) and slide them
along the chin straps to extract them.
- Withdraw the rear part of the head section from its
housing in order to remove it (Fig. C -D).
- To complete the operation, unclip the front of the
head section, starting with one side (Fig. E) and re
-
move the head section.
