Shark SV1106 N Owner's Manual

22 1-800-798-7398
CLEANING THE FILTER
Your vacuum has a high efficiency dust cup to maintain strong
suction by preventing debris from collecting on the filter. To
maintain strong suction, it is important to clean the foam filter
every month, under normal use.
1 Turn off the vacuum and remove the dust cup.
2 Remove the foam filter (a) and rinse under water until the
water runs clear. (b) Squeeze the excess water out of the
filter and let it air dry for 24 hours before replacing.
DO NOT use a hair dryer or other forced hot air to dry the
filter.
DO NOT operate the vacuum without the filter in place.
DO NOT operate the vacuum with a wet filter.
NOTE: It is normal for your foam filter to discolor over time; it will
not affect the filter performance.
CLEANING THE MOTORIZED FLOOR NOZZLE AND
CLEARING BLOCKAGES
An accumulation of hair, string, and other debris may sometimes
become lodged in the flexible air hose of the motorized floor
nozzle, in the air inlet of the dustcup or wrapped around the brush
roll. These areas must be free from debris for maximum cleaning
performance. To clear blockages and clean the brush roll:
1 Ensure the vacuum is off.
2 Press the release button located on the rear of the main body
and remove the motorized floor nozzle. (c)
3 To clear the air hose, flip back the connector to straighten
the air passage (d) and carefully remove any debris lodged
in the air hose. DO NOT USE SCISSORS OR OTHER SHARP
OBJECTS AS THESE MAY DAMAGE THE HOSE.
...continued on page 24.
a
b
c
d

Shark SV1106 N Specifications

General

Style	upright vacuums
Color	white and silver/gray, white
Floor Type	bare floor, carpet
Dust Bin Capacity	0.5 gallons
Filter	standard
Brush Roll Shut-Off	no
Bagless	yes
?leaning Area	10 inches
Voltage	120 volts

Weight and Dimensions

Length	10.5 inches
Height	46 inches
Width	9.87 inches
Net Weight	7 pounds
