Sharp 13N-M100B User Manual

10
13N-M100B/150B
CN13M10B
IC2001
IC2101
X
CRT
X
IC201
Data is stored in IC2101.
Adjust items related to picture tube only.
Holding down both the Vol-up/Ch-down buttons on the TV set at service mode for more than 2 seconds will automatically
write the above initial values into IC2101.
Table - D
The adjustment is needed to compensate for characteristics
of parts including IC201.
Holding down both the Vol-up/Ch-down buttons on the TV set
in the service mode for more than 2 seconds will automatically
write the above initial values into IC2101.
X
X
ADJUSTMENT
NECESSARY
UNNECESSARY
PART REPLACED
NOTES
