Sharp 13VT-K100 - Crt Unit

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
99
13VT-K100/150
13VT-CK10
R743 VRD-RM2HD823J J 82k 1/2W Carbon AA
R744 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R745 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R746 VRD-RA2BE122J J 1.2k 1/8W Carbon AA
R747 VRD-RM2HD473J J 47k 1/2W Carbon AA
R748 VRD-RA2EE182J J 1.8k 1/4W Carbon AA
R749 VRD-RA2EE222J J 2.2k 1/4W Carbon AA
R750 VRD-RA2EE392J J 3.9k 1/4W Carbon AA
R751 VRD-RA2BE104J J 100k 1/8W Carbon AA
R752 VRD-RM2HD104J J 100k 1/2W Carbon AA
R753 VRD-RA2BE223J J 22k 1/8W Carbon AA
R754 VRD-RA2BE563J J 56k 1/8W Carbon AA
R756 VRD-RM2HD221J J 220 1/2W Carbon AA
R766 VRD-RA2BE102J J 1k 1/8W Carbon AA
å R774 VRD-RA2BE102J J 1k 1/8W Carbon AA
å R775 VRD-RM2HD123J J 12k 1/2W Carbon AA
å R776 VRD-RM2HD153J J 15k 1/2W Carbon AA
MISCELLANEOUS PARTS
å RY701 RRLYU0038CEZZ J Relay 12V AM
å RY725 RRLYU0038CEZZ J Relay 12V AM
FB702 RBLN-0037CEZZ J Ferrite Bead AB
FB704 RBLN-0036CEZZ J Ferrite Bead AB
FB725 RBLN-0054CEZZ J Ferrite Bead AB
FB726 RBLN-0054CEZZ J Ferrite Bead AB
FB727 RBLN-0057CEZZ J Ferrite Bead AC
FB731 RBLN-0057CEZZ J Ferrite Bead AC
FB732 RBLN-0057CEZZ J Ferrite Bead AC
P351 QPLGN0261CEZZ J Plug, 2-pin (SP) AB
P352 QPLGN0361CEZZ J Plug, 3-pin (OR) AB
P701 QPLGN0207CEZZ J Plug, 2-pin (M) AA
P702 QPLGN0304CEZZ J Plug, 3-pin (E) AB
P705 QPLGN0361CEZZ J Plug, 3-pin (OC) AB
SC401 QSOCZ0840CEZZ J Socket, 8-pin (MA) AD
SC402 QSOCZ1040CEZZ J Socket, 10-pin (MB) AD
RDA701 PRDAR0209PEFW R Heat Sink, for IC701 AF
RDA765 PRDAR0232PEFW R Heat Sink, for IC756, AF
IC765
HM701 LX-GZ3001PEZZ R Screw AB
HM702 LX-GZ3001PEZZ R Screw AB
HM703 LX-GZ3001PEZZ R Screw AB
HM704 LX-GZ3001PEZZ R Screw AB
HM705 LX-GZ3001PEZZ R Screw AB
HM706 LX-GZ3001PEZZ R Screw AB
HM707 LX-GZ3001PEZZ R Screw AB
HM708 LX-GZ3001PEZZ R Screw AB
HM709 LX-GZ3001PEZZ R Screw AB
HM710 LX-GZ3001PEZZ R Screw AB
QCNW-2211PEZZ R Connecting Cord AD
QCNW-6008PEN3 R Connecting Cord (PG) AE
LX-BZ3049GEFD J Screw AA
LX-BZ3100CEFD J Screw AA
PWB-C: DUNTK9490WEV2
POWER Unit (Continued)
PWB-B: DUNTK8606WEV4
CRT Unit
TRANSISTORS
Q852 VS2SC2229O/1E J 2SC2229 (O) AD
Q854 VS2SC2229O/1E J 2SC2229 (O) AD
Q856 VS2SC2229O/1E J 2SC2229 (O) AD
Q881 VS2SA1266-Y-1 J 2SA1266 (Y) AA
DIODES
D881 VHD1SS119//-1 J Diode AB
D882 VHD1SS119//-1 J Diode AB
D885 VHD1SS119//-1 J Diode AB
CAPACITORS
(EL. : Electrolytic)
C851 VCCCPA1HH151J J 150p 50V Ceramic AA
C852 VCCCPA1HH151J J 150p 50V Ceramic AA
C853 VCCCPA1HH151J J 150p 50V Ceramic AA
C854 RC-KZ0016CEZZ J 0.01 1.4kV Ceramic AC
C881 VCEA0A1HW106M J 10 50V EL. AB
C883 VCEA0A1CW336M J 33 16V EL. AB
RESISTORS
(M.Ox. : Metal Oxide.)
R851 VRD-RA2BE470J J 47 1/8W Carbon AA
R852 VRD-RA2BE331J J 330 1/8W Carbon AA
R853 VRD-RA2BE121J J 120 1/8W Carbon AA
å R857 VRS-VV3AB123J J 12k 1W M.Ox. AA
R858 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R859 VRD-RA2BE470J J 47 1/8W Carbon AA
R860 VRD-RA2BE331J J 330 1/8W Carbon AA
R861 VRD-RA2BE121J J 120 1/8W Carbon AA
å R865 VRS-VV3AB123J J 12k 1W M.Ox. AA
R866 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R867 VRD-RA2BE470J J 47 1/8W Carbon AA
R868 VRD-RA2BE331J J 330 1/8W Carbon AA
R869 VRD-RA2BE121J J 120 1/8W Carbon AA
å R873 VRS-VV3AB123J J 12k 1W M.Ox. AA
R874 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R881 VRD-RA2BE102J J 1k 1/8W Carbon AA
R882 VRD-RA2BE221J J 220 1/8W Carbon AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0561CEZZ J Plug, 5-pin (GC) AB
P852 QPLGN0461CEZZ J Plug, 4-pin (YC) AB
SC851 QSOCV0842CEZZ J CRT Socket AH
QCNW-5025PEN4 R Connecting Cord (YC) AE
QCNW-5030PEN5 R Connecting Cord (GC) AE
