Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
104
13VT-K100/150
13VT-CK10
CABINET AND MECHANICAL PARTS
1 CCABA2444WEV0 J Cabinet Complete Ass'y BF
(13VT-K100)
1 CCABA2444WEV2 J Cabinet Complete Ass'y BE
(13VT-K150)
1 CCABA2444WEV4 J Cabinet Complete Ass'y BF
(13VT-CK10)
1-1 Not Available – Front Cabinet —
1-2 GCOVA0084PESA R Cover, R/C AE
1-3 HBDGB0014PESB R SHARP Badge AE
1-4 HDECQ0112PESA R Cassette Flap Door AG
(13VT-K100/13VT-CK10)
1-4 HDECQ0112PESB R Cassette Flap Door AG
(13VT-K150)
1-5 HDECQ0109PEKA R Decoration Plate AD
(13VT-K100/13VT-CK10)
1-5 HDECQ0109PEKB R Decoration Plate AD
(13VT-K150)
1-6 JBTN-0278PEKA R Power Button AC
(13VT-K100/13VT-CK10)
1-6 JBTN-0278PEKB R Power Button AD
(13VT-K150)
1-7 JBTN-0277PESA R TV Control Button AG
1-8 LHLDZ0040PEZZ R Bonding Boss AC
1-9 LX-TZ3004CEFD J Screw (TV3,VCR2,LED1) AA
1-10 MSPRC0005PEFW R Spring, for Power Button AB
1-11 MSPRD0123AJFJ J Spring, for Flap Door AC
1-12 PSPAH0012PE00 R Spacer AA
1-13 TCAUS0010PEZZ R Caution Label AB
(13VT-K100/150)
1-13 TCAUS0004PEZZ R Caution Label AB
(13VT-CK10)
1-14 TCAUS0013PEZZ R Caution Label(13VT-CK10) AB
2 GCABB2349PEKA R Rear Cabinet (13VT-K100) BB
2 GCABB2349PEKB R Rear Cabinet (13VT-K150) BB
2 GCABB2351PEKA R Rear Cabinet (13VT-CK10) BB
3 QACCD3051CESA J AC Cord AK
(13VT-K100/CK10)
3 QACCD3055CESB J AC Cord (13VT-K150) AK
4 QCNW-2206PEZZ R Connecting Cord AD
5 VSP9050PB15WA J Speaker AN
6 PSLDM0250PEFW R Shield AD
7 PSLDM0248PEFW R Top Shield AN
8 PSLDM0249PEFW R Bottom Shield AG
9 LANGT0038PEFW R Fixing Metal AC
10 QEARC1404PEZZ R Coating Earth AD
11 LCHSM0072PEKZ R Chassis Frame AQ
12 MSPRT0001PEFJ R Spring AC
13 PSPAG0022PE00 R Spacer AC
14 LX-TZ0012PEFD R Screw AC
15 PSLDM0253PEFW R Shield AC
16 LHLDW0003PEKZ R ADG Holder AB
17 LHLDW1047PEZZ R Holder AB
19 LHLDW1065PEKZ R Holder AD
20 PSPAG0004PEZZ R Spacer AB
21 TLABM1004PEZZ R Model Label AC
(13VT-K100/150)
21 TLABM1286PEZZ R Model Label AF
(13VT-CK10)
22 LX-TZ0013PEFD R Screw AD
23 LHLDW1064PEKZ R Holder AC
24 LX-HZ3001PEFD R Screw AA
25 XEBSD30P12000 J Screw AA
26 XHPSD30P06WS0 J Screw AA
27 XTASD40P20000 J Screw AA
28 XTASD40P20000 J Screw AA
å 30 VB370BVBK1S-S R Picture Tube (V101) BZ
å 31 RCiLH0160PEZZ R Deflection Yoke (DY601) BB
å 32 RCiLG0403PEZZ R Degaussing Coil AK
33 PMAGF3041CEZZ J Magnet AG
34 QSW-F0042AJZZ J Rec Tip Switch AG
35 QCNW-5025PEN4 R Connecting Cord (YC) AE
36 QCNW-5030PEN5 R Connecting Cord (GC) AE
38 PSLDM0251PEFW R Head Amp. Shield AD
39 LHLDZ1893AJ00 R Start/End Sensor Holder AB
40 LHLDZ0074PEZZ R Holder AC
41 LHLDW0014PEKZ R Wire Holder AB
42 LHLDK0009PEZZ R AC Cord Holder AC
43 LHLDK0011PEZZ R AC Cord Holder AE
