Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
40
14D1-S/G/W
14D2-S/G
D802 RH-DX0045GEZZY R Diode AA
D803 RH-DX0045GEZZY R Diode AA
D804 RH-DX0045GEZZY R Diode AA
D805 RH-DX0045GEZZY R Diode AA
D806 RH-DX0045GEZZY R Diode AA
D808 RH-EX0610GEZZY R Zener Diode 4.9V AA
D1001 RH-PX0013PEZZ R PhotoDiode AC
D1003 VHD1SS119//-1Y R 1SS119 AA
D1004 VHD1SS119//-1Y R 1SS119 AA
D1007 RH-EX0263TAZZY R Zener Diode AC
D1012 RH-EX0611GEZZY R Zener Diode 5V AA
D1018 RH-EX0263TAZZY R Zener Diode AC
D1019 RH-EX0263TAZZY R Zener Diode AC
D1024 VHD1SS119//-1Y R 1SS119 AA
å VA701 RH-VX0073CEZZ R Varistor AD
PACKAGED CIRCUITS
PR702 RMPTP0028CEZZ R Packaged Circuit AG
X1001 RCRSB0300CEZZ R Crystal AF
COILS AND TRANSFORMER
CF251 RFiLC0318CEZZ R Filter AG
CF252 RFiLC0465CEZZ R Filter AD
L202 VP-DF270K0000Y R Peaking 27µHAB
L203 VP-DF270K0000Y R Peaking 27µHAB
L251 VP-XF100K0000Y R Peaking 10µHAB
L252 VP-XF6R8K0000Y R Peaking 6.8µHAB
å L701 RCiLF0096PEZZ R Coil AF
L751 RCiLP0225CEZZ R Coil AF
L802 VP-DF100K0000Y R Peaking 10µHAB
L803 VP-DF100K0000Y R Peaking 10µHAB
L1030 VP-DF100K0000Y R Peaking 10µHAB
L1050 VP-DF100K0000Y R Peaking 10µHAB
L1051 VP-DF100K0000Y R Peaking 10µHAB
SF201 RFiLC0442CEZZ R Filter AL
å T601 RTRNZ0144PEZZ R Transformer AE
å T602 RTRNF0228PEZZ R H-Volt Transformer AX
å T701 RTRNW0015PEZZ R Transformer AL
CAPACITORS
C201 VCEA0A1CW476M+R 47 16V Electrolytic AB
C202 VCEA0A1AW337M+R 330 10V Electrolytic AC
C203 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C204 VCEA0A0JW477M+ R 470 6.3V Electrolytic AC
C205 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C206 VCEA0A1HW106M+R 10 50V Electrolytic AB
C231 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C232 VCKYCY1HB821K R 820p 50V Ceramic AA
C233 VCKYCY1HB472K R 4700p 50V Ceramic AA
C234 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C251 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C252 VCEA0A1CW107M+R 100 16V Electrolytic AC
C301 VCEA0A1CW477M+R 470 16V Electrolytic AC
C304 VCEA0A1CW106M+R 10 16V Electrolytic AB
C306 VCEA0A1CW106M+R 10 16V Electrolytic AB
C310 VCEA0A1HW105M+R 1 50V Electrolytic AB
C311 VCEA0A1HW105M+R 1 50V Electrolytic AB
C312 VCEA0A1HW224M+R 0.22 50V Electrolytic AB
C316 VCEA0A1CW107M+R 100 16V Electrolytic AC
C331 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C332 RC-QZA103TAYJ+ R 0.01 50V M.Polyester Film AB
C333 VCEA0A1CW108M R 1000 16V Electrolytic AD
C352 VCEA0A1HW105M+R 1 50V Electrolytic AB
C354 VCEA0A1HW105M+R 1 50V Electrolytic AB
C356 VCKYCY1HB472K R 4700p 50V Ceramic AA
C359 VCEA0A1CW106M+R 10 16V Electrolytic AB
C360 VCE9GA1HW225M+R 2.2 50V Elect.(N,P) AB
C409 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C410 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C411 VCKYCY1HB102K R 1000p 50V Ceramic AA
C412 VCEA0A1CW477M+R 470 16V Electrolytic AC
C501 VCKYPA1HB102K+ R 1000p 50V Ceramic AA
C504 VCKYCY1HB103K R 0.01 50V Ceramic AA
C505 VCEA0A1HW107M+R 100 50V Electrolytic AB
C507 VCKYCY1HB103K R 0.01 50V Ceramic AA
C508 VCFYSA1JB224J+ R 0.22 63V Mylar AD
C509 VCEA0A1CW477M+R 470 16V Electrolytic AC
C510 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C514 VCFYSA1JB563J+ R 0.056 63V Mylar AD
C529 VCKYCY1CB823KY R 0.082 16V Ceramic AH
C531 VCKYCY1HB102K R 1000p 50V Ceramic AA
C532 VCKYCY1HB102K R 1000p 50V Ceramic AA
C533 RC-QZA104TAYJ+ R 0.1 50V M.Polyester Film AB
C601 RC-QZA563TAYJ+ R 0.056 50V M.Polyester Film AB
C602 VCEA0A1HW475M+R 4.7 50V Electrolytic AB
C603 VCEA0A1HW105M+R 1 50V Electrolytic AB
C604 VCEA0A2EW106M R 10 250V Electrolytic AD
C605 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C606 VCFPFA2EB334J R 0.33 250V M.Polypro AD
C607 VCFPFD3ZA532H R 5300p 1.8kVM.Polypro AD
C608 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C610 VCEA0A1CW108M R 1000 16V Electrolytic AD
C611 VCEA0A1EW476M+R 47 25V Electrolytic AB
C612 VCEA0A1CW477M+R 470 16V Electrolytic AC
C620 VCKYPA2HB102K+ R 1000p 500V Ceramic AA
C640 VCFYSB2EB823J R 0.082 250V M.Polyester Film AD
C651 VCQYTA1HM222J+ R 2200p 50V Mylar AA
C652 RC-QZA472TAYJ+ R 4700p 50V Mylar AB
C653 VCEA0A1HW105M+R 1 50V Electrolytic AB
C654 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C655 VCEA0A1HW106M+R 10 50V Electrolytic AB
C656 VCEA0A1HW474M+R 0.47 50V Electrolytic AB
C657 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C658 VCKYCY1EF104Z R 0.1 25V Ceramic AA
å C701 RC-FZ031SCEZZ R 0.1 275V M.Polyester Film AD
C702 RC-KZ0029CEZZ+ R 0.01 250V Ceramic AC
C703 RC-KZ0029CEZZ+ R 0.01 250V Ceramic AC
C704 RC-KZ0029CEZZ+ R 0.01 250V Ceramic AC
C705 RC-EZ1286CEZZ R 150 400V Electrolytic AT
C709 RC-KZ0039CEZZ R 680p 2kV Ceramic AB
C710 VCEA0A1HW476M+R 47 50V Electrolytic AB
C711 VCKYPA1HB102K+ R 1000p 50V Ceramic AA
C712 VCKYPA1HB471K+ R 470p 50V Ceramic AA
å C751 RC-KZ0102GEZZ R 680 AC250V Ceramic AE
C752 VCKYPH3DB561K R 560p 2kV Ceramic AC
C753 RC-EZ0776CEZZ R 100 160V Electrolytic AF
C754 RC-EZA069WJZZ R 33 160V Electrolytic AE
C755 VCEA0A1CW108M R 1000 16V Electrolytic AD
C756 RC-QZA103TAYJ+ R 0.01 50V M.Polyester Film AB
C759 VCEA0A0JW477M+ R 470 6.3V Electrolytic AC
C760 VCEA0A0JW228M R 2200 6.3V Electrolytic AD
C801 VCEA0A1HW105M+R 1 50V Electrolytic AB
C803 VCEA0A1CW107M+R 100 16V Electrolytic AC
C804 VCKYCY1HB222K R 2200p 50V Ceramic AA
C805 VCKYD41HB102KY R 1000p 50V Ceramic AA
C806 VCKYD41HB102KY R 1000p 50V Ceramic AA
C807 VCKYD41HB102KY R 1000p 50V Ceramic AA
C808 VCEA0A1CW107M+R 100 16V Electrolytic AC
C809 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C810 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C811 VCEA0A1CW107M+R 100 16V Electrolytic AC
C812 VCFYFA1HA224J+ R 0.22 50V M.Polyester Film AB
C813 VCFYFA1HA224J+ R 0.22 50V M.Polyester Film AB
C814 VCKYCY1HB471K R 470p 50V Ceramic AA
C816 VCKYCY1HB471K R 470p 50V Ceramic AA
C1001 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB
C1002 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB
C1003 VCEA0A1CW106M+R 10 16V Electrolytic AB
C1004 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1005 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1006 VCEA0A1CW106M+R 10 16V Electrolytic AB
C1008 VCCCCY1HH330J R 33p 50V Ceramic AA
C1009 VCCCCY1HH330J R 33p 50V Ceramic AA
C1010 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB
C1011 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1012 VCKYCY1CF474Z R 0.47 16V Ceramic AB
C1013 VCEA0A0JW107M+ R 100 6.3V Electrolytic AB
C1014 VCEA0A1CW106M+R 10 16V Electrolytic AB
C1016 RC-QZA104TAYJ+ R 0.1 50V Mylar AB
C1018 VCKYCY1HB221K R 220p 50V Ceramic AA
C1019 VCEA0A1HW225M+R 2.2 50V Electrolytic AB
C1024 RC-QZA104TAYJ+ R 0.1 50V Mylar AB
