Sharp 14D2-G User Manual

Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
41
14D1-S/G/W
14D2-S/G
RESISTORS
RJ2 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ9 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ13 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ14 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ15 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ16 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ17 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ18 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ19 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ24 VRN-MD2AL000J R 0 1/10W Metal Film AA
(14D2-S/G)
RJ26 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ28 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ32 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ33 VRN-MD2AL000J R 0 1/10W Metal Film AA
(14D2-S/G)
RJ35 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ37 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ38 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ41 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ42 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ43 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ46 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ47 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ49 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ50 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ51 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ52 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ53 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ56 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ71 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ73 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ75 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ76 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ77 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ78 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ83 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ88 VRN-MD2AL000J R 0 1/10W Metal Film AA
R217 VRN-MD2AL000J R 0 1/10W Metal Film AA
R230 VRN-MD2AL000J R 0 1/10W Metal Film AA
R364 VRN-MD2AL000J R 0 1/10W Metal Film AA
R366 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ10 VRS-CY1JF000JY R 0 1/16W Metal Oxide AA
RJ21 VRS-CY1JF000JY R 0 1/16W Metal Oxide AA
R201 VRN-MD2AL101J R 100 1/10W Metal Film AA
R202 VRN-MD2AL101J R 100 1/10W Metal Film AA
R216 VRS-VV3LB223J R 22k 3W Metal Oxide AB
R219 VRD-RA2BE392JY R 3.9k 1/8W Carbon AA
R231 VRD-RA2BE681JY R 680 1/8W Carbon AA
R232 VRN-MD2AL272J R 2.7k 1/10W Metal Film AA
R233 VRN-MD2AL102J R 1k 1/10W Metal Film AA
R234 VRN-MD2AL391J R 390 1/10W Metal Film AA
R251 VRN-MD2AL181J R 180 1/10W Metal Film AA
R252 VRN-MD2AL181J R 180 1/10W Metal Film AA
R253 VRD-RA2BE680JY R 68 1/8W Carbon AA
R254 VRN-MD2AL560J R 56 1/10W Metal Film AB
R255 VRN-MD2AL223J R 22k 1/10W Metal Film AA
R256 VRN-MD2AL223J R 22k 1/10W Metal Film AA
R262 VRN-MD2AL560J R 56 1/10W Metal Film AB
R263 VRN-MD2AL560J R 56 1/10W Metal Film AB
R301 VRN-MD2AL101J R 100 1/10W Metal Film AA
R302 VRN-MD2AL101J R 100 1/10W Metal Film AA
R303 VRN-MD2AL561J R 560 1/10W Metal Film AA
R304 VRN-MD2AL100J R 10 1/10W Metal Film AA
R305 VRN-MD2AL274J R 270k 1/10W Metal Film AA
R310 VRN-MD2AL473J R 47k 1/10W Metal Film AA
R311 VRN-MD2AL473J R 47k 1/10W Metal Film AA
R313 VRN-MD2AL102J R 1k 1/10W Metal Film AA
R314 VRN-MD2AL472J R 4.7k 1/10W Metal Film AA
R315 VRN-MD2AL272J R 2.7k 1/10W Metal Film AA
R316 VRN-MD2AL272J R 2.7k 1/10W Metal Film AA
R318 VRD-RA2BE680JY R 68 1/8W Carbon AA
R334 VRN-MD2AL332J R 3.3k 1/10W Metal Film AA
R335 VRS-CY1JF564JY R 560k 1/16W Metal Oxide AA
R352 VRN-MD2AL681J R 680 1/10W Metal Film AA
R359 VRN-MD2AL102J R 1k 1/10W Metal Film AA
R360 VRN-MD2AL103J R 10k 1/10W Metal Film AA
R361 VRN-MD2AL104J R 100k 1/10W Metal Film AA
R431 VRN-MD2AL101J R 100 1/10W Metal Film AA
R432 VRN-MD2AL820J R 82 1/10W Metal Film AA
R458 VRN-MD2AL103J R 10k 1/10W Metal Film AA
R459 VRD-RA2BE680JY R 68 1/8W Carbon AA
R501 VRD-RA2BE272JY R 2.7k 1/8W Carbon AA
R502 VRD-RM2HD102JY R 1k 1/2W Carbon AA
R503 VRN-VV3AB2R7J R 2.7 1W Metal Film AA
R504 VRN-MD2AL181J R 180 1/10W Metal Film AA
R505 VRN-MD2AL102J R 1k 1/10W Metal Film AA
R506 VRS-VV3AB331J R 330 1W Metal Oxide AA
R507 VRN-VV3AB1R0J R 1 1W Metal Film AA
R508 VRD-RA2BE153JY R 15k 1/8W Carbon AA
R509 VRD-RA2BE153JY R 15k 1/8W Carbon AA
R511 VRN-MD2AL181J R 180 1/10W Metal Film AA
R512 VRD-RM2HD5R6JY R 5.6 1/2W Carbon AA
R521 VRD-RA2BE333JY R 33k 1/8W Carbon AA
R529 VRD-RA2BE223JY R 22k 1/8W Carbon AA
R530 VRS-CY1JF334JY R 330k 1/16W Metal Oxide AA
R531 VRN-MD2AL101J R 100 1/10W Metal Film AA
R532 VRN-MD2AL101J R 100 1/10W Metal Film AA
R533 VRD-RA2BE393JY R 39k 1/8W Carbon AA
R601 VRS-SV2HC102J R 1k 1/2W Metal Oxide AA
R602 VRD-RA2BE393JY R 39k 1/8W Carbon AA
R603 VRD-RA2BE273JY R 27k 1/8W Carbon AA
R604 VRD-RA2BE563JY R 56k 1/8W Carbon AA
R605 VRD-RM2HD124JY R 120k 1/2W Carbon AA
R606 VRN-VV3AB1R5J R 1.5 1W Metal Film AA
R607 VRD-RM2HD270JY R 27 1/2W Carbon AA
R609 VRD-RA2BE154JY R 150k 1/8W Carbon AA
R610 VRD-RA2BE102GY R 1k 1/8W Carbon AB
R611 VRN-MD2AL102J R 1k 1/10W Metal Film AA
R612 VRN-MD2AL123J R 12k 1/10W Metal Film AA
R613 VRN-MD2AL103J R 10k 1/10W Metal Film AA
R614 VRS-SV2HC150J R 15 1/2W Metal Oxide AA
R615 VRS-VV3DB682J R 6.8k 2W Metal Oxide AA
R616 VRN-VV3ABR47J R 0.47 1W Metal Film AA
R618 VRS-VV3DB391J R 390 2W Metal Oxide AA
R619 VRS-VV3LB103J R 10k 3W Metal Oxide AB
R620 VRS-VV3AB472J R 4.7k 1W Metal Oxide AA
R622 VRD-RA2BE102JY R 1k 1/8W Carbon AA
R623 VRD-RM2HD184JY R 180k 1/2W Carbon AA
R624 VRN-MD2AL472J R 4.7k 1/10W Metal Film AA
R625 VRN-VV3DB8R2J R 8.2 2W Metal Film AB
R626 VRD-RM2HD470JY R 47 1/2W Carbon AA
R633 VRD-RA2BE333JY R 33k 1/8W Carbon AA
R634 VRD-RA2BE103JY R 10k 1/8W Carbon AA
R641 VRN-SV2HCR47J R 0.47 1/2W Metal Film AA
R651 VRN-MD2AL223J R 22k 1/10W Metal Film AA
R652 VRN-MD2AL102J R 1k 1/10W Metal Film AA
R653 VRN-MD2AL822J R 8.2k 1/10W Metal Film AA
R654 VRN-MD2AL273J R 27k 1/10W Metal Film AA
R655 VRN-MD2AL391J R 390 1/10W Metal Film AA
R656 VRN-MD2AL100J R 10 1/10W Metal Film AA
R658 VRD-RA2BE101JY R 100 1/8W Carbon AA
R663 VRD-RA2BE101JY R 100 1/8W Carbon AA
R701 VRW-KQ3NC3R9K R 3.9 7W Cement AE
R707 VRS-VV3DB104J R 100k 2W Metal Oxide AB
R708 VRD-RA2BE681JY R 680 1/8W Carbon AA
R709 VRN-VV3DBR47J R 0.47 2W Metal Film AB
R710 VRN-VV3DBR56J R 0.56 2W Metal Film AA
(14D1-S/G/W)
R710 VRN-VV3DBR47J R 0.47 2W Metal Film AB
(14D2-S/G)
R711 VRD-RA2BE682JY R 6.8k 1/8W Carbon AA
R712 VRD-RA2BE152JY R 1.5k 1/8W Carbon AA
R716 VRD-RA2BE562JY R 5.6k 1/8W Carbon AA
å R751 VRC-UA2HG825KY R 8.2M 1/2W Solid AA
å R752 VRC-UA2HG825KY R 8.2M 1/2W Solid AA
R753 VRD-RM2HD124JY R 120k 1/2W Carbon AA
R754 VRD-RM2HD150JY R 15 1/2W Carbon AA
R755 VRD-RA2BE221JY R 220 1/8W Carbon AA
R756 VRD-RM2HD270JY R 27 1/2W Carbon AA
R757 VRN-MD2AL151J R 150 1/10W Metal Film AA
R801 VRN-MD2AL221J R 220 1/10W Metal Film AA
