Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
32
14SL30
21SL40, 21SL70
Q753 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q2001 VS2SD601AR/-1 J 2SD601 AR AC
Q2002 VS2SD601AR/-1 J 2SD601 AR AC
Q2060 VS2SC2462-C-1 J 2SC2462(C) AB
DIODES
D51 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D52 RH-EX0676GEZZ J Zener Diode, 32V AA
D53 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D103 VHD1SS119//-1 J Diode AB
D401 VHD1SS119//-1 J Diode AB
D402 RH-EX0092CEZZ J Zener Diode, 3.9V AB
D454 RH-EX0103CEZZ J Zener Diode, 5.6V AB
D455 VHD1SS119//-1 J Diode AB
D501 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D502 RH-DX0131CEZZ J Diode AC
D641 RH-EX0631GEZZ J Zener Diode, 9.1V AA
çå D651 RH-DX0131CEZZ J Diode AC
çå D652 VHD1SS119//-1 J Diode AB
çå D653 RH-EX0091CEZZ J Zener Diode, 22V AB
å D661 RH-DX0444CEZZ J Diode AH
å D701 RH-DX0386CEZZ J Diode AG
å D702 RH-DX0279CEZZ J Diode AB
å D703 RH-DX0279CEZZ J Diode AB
å D704 RH-DX0279CEZZ J Diode AB
D705 RH-DX0492CEZZ J Diode AE
D706 VHD1SS82///1A J Diode AC
D707 VHD1SS82///1A J Diode AC
D708 RH-DX0400CEZZ J Diode AC
D709 RH-DX0164CEZZ J Diode AC
D710 RH-EX0601GEZZ J Zener Diode, 3.6V AA
å D711 RH-DX0279CEZZ J Diode AB
D712 RH-DX0132CEZZ J Diode AC
D751 VHD1SS119//-1 J Diode AB
D752 RH-DX0406CEZZ J Diode AD
D753 RH-EX0641GEZZ J Zener Diode, 12V AA
D754 RH-DX0445CEZZ J Diode AL
D755 RH-DX0461CEZZ J Diode AG
D756 VHD1SS119//-1 J Diode AB
å D758 RH-DX0131CEZZ J Diode AC
D2001 VHD1SS119//-1 J Diode AB
D2002 RH-PX0348CEZZ J Photodiode AB
D2007 RH-EX0611GEZZ J Zener Diode, 5.1V AA
å VA701 RH-VX0048CEZZ J Varistor AE
PACKGED CIRCUITS
å PR701 RMPTP0062CEZZ J Packaged Circuit AH
X801 RCRSB0205CEZZ J Crystal AF
or
RCRSB0001PEZZ
FILTERS
CF301 RFiLC0403CEZZ J Ceramic Filter AE
or
RFiLC0029TAZZ
CF401 RFiLC0013CEZZ J Ceramic Filter AE
or
RFiLC0004PEZZ
CF631 RFiLA0034CEZZ J Ceramic Filter AD
CF2040 RFiLC0121GEZZ J Ceramic Filter AD
SF201 RFiLC0405CEZZ J SAW Filter AH
COILS
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 RCiLi0612CEZZ J IF Coil AE
or
RCiLi0588CEZZ
L301 VP-XF8R2K0000 J Peaking 8.2µH AB
L302 RCiLi0613CEZZ J IF Coil AE
or
RCiLi0605CEZZ
L401 VP-XF6R8K0000 J Peaking 6.8µH AB
L402 VP-XF3R3K0000 J Peaking 3.3µH AB
L403 VP-XF100K0000 J Peaking 10µH AB
L404 VP-XF8R2K0000 J Peaking 8.2µH AB
L406 VP-XF680K0000 J Peaking 68µH AB
L409 VP-XF100K0000 J Peaking 10µH AB
L631 VP-XF120K0000 J Peaking 12µH AB
å L701 RCiLF0012PEZZ R Coil AN
or
RCiLF0043PEZZ
or
RCiLF0019PEZZ
å L702 RCiLF0012PEZZ R Coil AN
or
RCiLF0021PEZZ
L751 RCiLP0225CEZZ J Coil AF
L2040 RCiLB0159CEZZ J Oscillation Coil AE
TRANSFORMERS
å T601 RTRNZ0367CEZZ J H-Driver AK
çå T602 RTRNF0147PEZZ R F.B.T BC
å T701 RTRNZ0138PEZZ R Transformer AW
å T702 RTRNZ0103GJZZ X Transformer
or
RTRNZ0104GJZZ
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C51 VCEA0A1CW476M J 47 16V EL. AB
C52 VCSATA1CE226K J 22 16V Tantalum AD
C53 VCEA0A1HW105M J 1.0 50V EL. AB
C54 VCEA0A1HW475M J 4.7 50V EL. AB
or
VCEA0A1HW225M 2.2 50V EL.
C55 VCEA0A1CW477M J 470 16V EL. AC
or
VCEAGA1CW108M 1000 16V EL.
C102 VCEAGA1CW228M J 2200 16V EL. AE
C201 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C202 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C204 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C205 VCEA0A1HW474M J 0.47 50V EL. AB
C206 VCEA0A1CW227M J 220 16V EL. AC
C207 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C208 VCEA0A1HW474M J 0.47 50V EL. AB
C209 VCKYCY1HB222K J 2200p 50V Ceramic AA
C210 VCKYCY1HB102K J 1000p 50V Ceramic AA
C302 VCCCCY1HH330J J 33p 50V Ceramic AA
C303 VCKYCY1HB472K J 4700p 50V Ceramic AA
C304 VCEA0A1HW225M J 2.2 50V EL. AB
C305 VCKYPA1HB151K J 150p 50V Ceramic AA
C306 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C307 VCEA0A1CW477M J 470 16V EL. AC
C308 VCKYCY1HB102K J 1000p 50V Ceramic AA
C309 VCEA0A1CW227M J 220 16V EL. AC
C312 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C402 VCCCCY1HH331J J 330p 50V Ceramic AA
C403 VCCCCY1HH101J J 100p 50V Ceramic AA
C405 VCEA0A1HW335M J 3.3 50V EL. AB
C406 VCEA0A1HW335M J 3.3 50V EL. AB
C408 VCEA0A1CW106M J 10 16V EL. AB
C409 VCEA0A1HW105M J 1.0 50V EL. AB
C410 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C411 VCEAGA1CW108M J 1000 16V EL. AD
C413 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C414 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C419 VCCCCY1HH330J J 33p 50V Ceramic AA
C420 VCCCCY1HH471J J 470p 50V Ceramic AA
C451 VCQYTA1HM563K J 0.056 50V Mylar AB
C454 VCEA0A1HW475M J 4.7 50V EL. AB
C502 VCEA0A1EW477M J 470 25V EL. AD
C504 VCKYPA2HB391K J 390p 500V Ceramic AA
C505 VCQYTA1HM473K J 0.047 50V Mylar AB
PWB-A: DUNTK9882WEV1 (21SL40)
MAIN UNIT (Continued)
