Sharp 14SL30 User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
33
14SL30
21SL40, 21SL70
C507 VCQYTA1HM103K J 0.01 50V Mylar AB
C508 VCEAGA1VW107M J 100 35V EL. AC
C509 VCKYPA2HB102K J 1000p 500V Ceramic AA
C510 VCEAGA1VW477M J 470 35V EL. AD
C511 VCQYTA1HM473K J 0.047 50V Mylar AB
C513 VCEACA1HC225M J 2.2 50V EL. AC
C514 VCEACA1HC225J J 2.2 50V EL. AC
C517 VCKYPA1HB102K J 1000p 50V Ceramic AA
C522 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C551 VCSATA1CE225K J 2.2 16V Tantalu AB
C552 VCEA0A1HW225M J 2.2 50V EL. AB
C603 VCKYPA2HB562K J 5600p 500V Ceramic AC
å C604 VCEAGH2CW227M J 220 160V EL. AH
çå C608 VCFPPD3CA842H J 8400p 1.6kV M-Poly AE
C609 VCKYPA2HB222K J 2200p 500V Ceramic AA
C612 VCFPPJ2EB564J J 0.56 250V M-Poly. AF
C631 VCEA0A1HW225M J 2.2 50V EL. AB
C632 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C634 VCEA0A1CW477M J 470 16V EL. AC
C652 VCEA0A1HW475M J 4.7 50V EL. AB
C653 VCEA0A1CW106M J 10 16V EL. AB
C661 VCKYPA2HB152K J 1500p 500V Ceramic AA
C662 VCEA0A1CW477M J 470 16V EL. AC
å C701 RC-FZ027SCEZZ J 0.047 AC250V Plastic AD
or
RC-FZ015SCEZZ
or
RC-FZ0168CEZZ
or
RC-FZ010SCEZZ
or
RC-FZ002SCEZZ
or
RC-FZ027CUMZZ
or
RC-FZ059SCEZZ
C702 RC-KZ0160GEZZ J 0.01 AC250V Ceramic AC
or
RC-KZ0029CEZZ
C703 RC-KZ0160GEZZ J 0.01 AC250V Ceramic AC
or
RC-KZ0029CEZZ
C704 VCEA0A2GW475M J 4.7 400V EL. AE
C705 RC-QZA104TAYK J 0.1 50V Mylar AB
å C707 RC-EZ0804CEZZ J 220 400V EL. AU
C708 RC-KZ1022CEZZ J 47p 1kV Ceramic AC
C709 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C710 RC-QZA471TAYJ J 470p 50V Mylar AB
C711 RC-KZ0339CEZZ J 680p 2kV Ceramic AD
C712 RC-QZA102TAYJ J 1000p 50V Mylar AB
C713 RC-KZ007JCEZZ J 0.01 250V Ceramic AC
C714 RC-KZ0338CEZZ J 560p 2kV Ceramic AD
C715 VCKYPA2HB102K J 1000p 500V Ceramic AA
C716 VCEAGA1EW107M J 100 25V EL. AD
C717 RC-QZA182TAYJ J 1800p 50V Mylar AB
C718 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C719 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C720 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C721 VCKYPA2HB821K J 820p 500V Ceramic AA
å C730 RC-KZ0155CEZZ J 680p 4kV Ceramic AE
or
RC-KZ0156CEZZ 3300p 4kV
C751 VCEA0A1CW107M J 100 16V EL. AC
C752 VCEA0A1CW108M J 1000 16V EL. AD
C754 VCEAGA1EW108M J 1000 25V EL. AD
C755 VCKYPA2HB102K J 1000p 500V Ceramic AA
C756 VCKYD41HB102K J 1000p 50V Ceramic AA
å C757 VCEA4W2CN227M J 220 160V EL. AG
C758 VCEAGA2EW106M J 10 250V EL. AC
C759 VCKYPA2HB102K J 1000p 500V Ceramic AA
C760 VCEA0A1CW337M J 330 16V EL. AC
C761 VCQYTA1HM104K J 0.1 50V Mylar AC
C762 RC-KZ0339CEZZ J 680p 2kV Ceramic AD
C763 RC-QZA473TAYJ J 0.047 50V Mylar AB
C766 VCEA0A1CW476M J 47 16V EL. AB
C767 VCEA0A1CW107M J 100 16V EL. AC
C801 RC-QZA223TAYK J 0.022 50V Mylar AB
C802 VCEA0A1HW474M J 0.47 50V EL. AB
C803 VCCCCY1HH120J J 12p 50V Ceramic AA
C804 VCEA0A1HW104M J 0.1 50V EL. AB
C805 VCEA0A1HW104M J 0.1 50V EL. AB
C806 VCEA0A1HW104M J 0.1 50V EL. AB
C807 VCCCCY1HH820J J 82p 50V Ceramic AA
C901 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C905 VCEA0A1HW335M J 3.3 50V EL. AB
C2001 VCCCCY1HH101J J 100p 50V Ceramic AA
C2002 VCCCCY1HH101J J 100p 50V Ceramic AA
C2021 VCCCCY1HH101J J 100p 50V Ceramic AA
C2022 VCCCCY1HH101J J 100p 50V Ceramic AA
C2023 VCCCCY1HH101J J 100p 50V Ceramic AA
C2024 VCCCCY1HH101J J 100p 50V Ceramic AA
C2040 VCEA0A1AW107M J 100 10V EL. AB
C2041 VCEA0A1HW105M J 1.0 50V EL. AB
C2060 VCQYTA1HM104K J 0.1 50V Mylar AC
C2061 VCCCPA1HH101J J 100p 50V Ceramic AA
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2401 VCCCPA1HH560J J 56p 50V Ceramic AA
C2402 VCCCPA1HH560J J 56p 50V Ceramic AA
C2601 VCEA0A1CW476M J 47 16V EL. AB
C2602 VCCCCY1HH101J J 100p 50V Ceramic AA
C5301 VCEAGA1VW108M J 1000 35V EL. AD
C5304 VCEAGA1HW225M J 2.2 50V EL. AB
C5305 VCEAGA1CW226M J 22 16V EL. AB
C5307 RC-QZA272TAYK J 2700p 50V Mylar AB
C5308 VCEAGA1VW107M J 100 35V EL. AC
C5309 VCEAGA1EW108M J 1000 25V EL. AD
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ8 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ12 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ13 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ14 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ17 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ18 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ19 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ20 VRS-CY1JF000J J 0 1/16W M-Ox. AA
å R51 VRS-VV3AB331J J 330 1W M-Ox. AA
or
VRS-VV3DB151J 150 2W M-Ox.
å R52 VRS-VV3DB470J J 47 2W M-Ox. AA
or
VRD-RA2BE1R0J 1.0 1/8W Carbon
å R53 VRS-VV3LB223J J 22k 3W M-Ox. AB
R54 VRD-RA2BE101J J 100 1/8W Carbon AB
R55 VRD-RA2BE101J J 100 1/8W Carbon AB
R56 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R57 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
or
VRS-CY1JF103J 10k 1/16W M-Ox.
R201 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R202 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R203 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R204 VRS-CY1JF270J J 27 1/16W M-Ox. AA
R205 VRS-CY1JF391J J 390 1/16W M-Ox. AA
PWB-A: DUNTK9882WEV1 (21SL40)
MAIN UNIT (Continued)
