Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
37
14SL30
21SL40, 21SL70
C517 VCKYPA1HB102K J 1000p 50V Ceramic AA
C522 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C551 VCSATA1CE225K J 2.2 16V Tantalum AB
C552 VCEA0A1HW225M J 2.2 50V EL. AB
C603 VCKYPA2HB222K J 2200p 500V Ceramic AA
(14SL30)
C603 VCKYPA2HB562K J 5600p 500V Ceramic AC
(21SL70)
å C604 VCEAGH2CW227M J 220 160V EL. AH
çå C608 VCFPPD3CA682H J 6800p 1.6kV M-Poly. AE
(14SL30)
çå C608 VCFPPD3CA842H J 8400p 1.6kV M-Poly. AE
(21SL70)
C609 VCKYPA2HB102K J 1000p 500V Ceramic AA
(14SL30)
C609 VCKYPA2HB222K J 2200p 500V Ceramic AA
(21SL70)
C612 VCFPPJ2EB474J J 0.47 250V M-Poly. AF
(14SL30)
C612 VCFPPJ2EB564J J 0.56 250V M-Poly. AF
(21SL70)
C631 VCEA0A1HW225M J 2.2 50V EL. AB
C632 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C634 VCEA0A1CW477M J 470 16V EL. AC
C652 VCEA0A1HW475M J 4.7 50V EL. AB
C653 VCEA0A1CW106M J 10 16V EL. AB
C661 VCKYPA2HB152K J 1500p 500V Ceramic AA
C662 VCEA0A1CW477M J 470 16V EL. AC
å C701 RC-FZ027SCEZZ J 0.047 AC250V Plastic AD
or
RC-FZ015SCEZZ
or
RC-FZ0168CEZZ
or
RC-FZ010SCEZZ
or
RC-FZ002SCEZZ
or
RC-FZ027CUMZZ
or
RC-FZ059SCEZZ
C702 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C703 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C704 VCEA0A2GW475M J 4.7 400V EL. AE
C705 RC-QZA104TAYK J 0.1 50V Mylar AB
å C707 RC-EZ0804CEZZ J 220 400V EL. AU
C708 RC-KZ1022CEZZ J 47p 1kV Ceramic AC
C709 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C710 RC-QZA471TAYJ J 470p 50V Mylar AB
C711 RC-KZ0339CEZZ J 680p 2kV Ceramic AD
C712 RC-QZA102TAYJ J 1000p 50V Mylar AB
C713 RC-KZ007JCEZZ J 0.01 250V Ceramic AC
C714 RC-KZ0338CEZZ J 560p 2kV Ceramic AD
C715 VCKYPA2HB102K J 1000p 500V Ceramic AA
C716 VCEAGA1EW107M J 100 25V EL. AD
C717 RC-QZA182TAYJ J 1800p 50V Mylar AB
C718 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C719 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C720 RC-KZ0160GEZZ J 0.01 250V Ceramic AC
or
RC-KZ0029CEZZ
C721 VCKYPA2HB821K J 820p 500V Ceramic AA
å C730 RC-KZ0155CEZZ J 680p 4kV Ceramic AE
or
RC-KZ0156CEZZ 3300p 4kV
C751 VCEA0A1CW107M J 100 16V EL. AC
C752 VCEA0A1CW108M J 1000 16V EL. AD
C754 VCEAGA1EW108M J 1000 25V EL. AD
C755 VCKYPA2HB102K J 1000p 500V Ceramic AA
C756 VCKYD41HB102K J 1000p 50V Ceramic AA
å C757 VCEA4W2CN227M J 220 160V EL. AG
C758 VCEAGA2EW106M J 10 250V EL. AC
C759 VCKYPA2HB102K J 1000p 500V Ceramic AA
C760 VCEA0A1CW337M J 330 16V EL. AC
C761 VCQYTA1HM104K J 0.1 50V Mylar AC
C762 RC-KZ0339CEZZ J 680p 2kV Ceramic AD
C763 RC-QZA473TAYJ J 0.047 50V Mylar AB
C766 VCEA0A1CW476M J 47 16V EL. AB
C767 VCEA0A1CW107M J 100 16V EL. AC
C801 RC-QZA223TAYK J 0.022 50V Mylar AB
C802 VCEA0A1HW474M J 0.47 50V EL. AB
C803 VCCCCY1HH120J J 12p 50V Ceramic AA
C804 VCEA0A1HW104M J 0.1 50V EL. AB
C805 VCEA0A1HW104M J 0.1 50V EL. AB
C806 VCEA0A1HW104M J 0.1 50V EL. AB
C807 VCCCCY1HH820J J 82p 50V Ceramic AA
C901 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C904 VCEA0A1HW335M J 3.3 50V EL. (21SL70) AB
C905 VCEA0A1HW335M J 3.3 50V EL. AA
C950 VCEAGA1CW108M J 1000 16V EL. (21SL70) AD
C951 VCEA0A1HW335M J 3.3 50V EL. (21SL70) AB
C952 VCCCCY1HH681J J 680p 50V Ceramic AB
(21SL70)
C953 VCEA0A1HW335M J 3.3 50V EL. (21SL70) AB
C954 VCQYTA1HM183K J 0.018 50V Mylar AB
(21SL70)
C960 VCEA0A1CW227M J 220 16V EL. (21SL70) AC
C961 VCEA0A1HW335M J 3.3 50V EL. (21SL70) AB
C962 VCCCCY1HH681J J 680p 50V Ceramic AB
(21SL70)
C963 VCEA0A1HW335M J 3.3 50V EL. (21SL70) AB
C964 VCQYTA1HM183K J 0.018 50V Mylar AB
(21SL70)
C2001 VCCCCY1HH101J J 100p 50V Ceramic AA
C2002 VCCCCY1HH101J J 100p 50V Ceramic AA
C2021 VCCCCY1HH101J J 100p 50V Ceramic AA
C2022 VCCCCY1HH101J J 100p 50V Ceramic AA
C2023 VCCCCY1HH101J J 100p 50V Ceramic AA
C2024 VCCCCY1HH101J J 100p 50V Ceramic AA
C2040 VCEA0A1AW107M J 100 10V EL. AB
C2041 VCEA0A1HW105M J 1.0 50V EL. AB
C2060 VCQYTA1HM104K J 0.1 50V Mylar AC
C2061 VCCCPA1HH101J J 100p 50V Ceramic AA
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2401 VCCCPA1HH560J J 56p 50V Ceramic AA
C2402 VCCCPA1HH560J J 56p 50V Ceramic AA
C2601 VCEA0A1CW476M J 47 16V EL. AB
C2602 VCCCCY1HH101J J 100p 50V Ceramic AA
C3001 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
(21SL70)
C3002 VCKYCY1HB562K J 5600p 50V Ceramic AA
(21SL70)
C3003 RC-QZA123TAYK J 0.012 50V Mylar AB
(21SL70)
C3004 VCEA0A1HW105M J 1.0 50V EL. (21SL70) AB
C3005 VCEA0A1HW475M J 4.7 50V EL. (21SL70) AB
C3006 VCEA0A1HW106M J 10 50V EL. (21SL70) AB
C3007 VCEA0A1HW475M J 4.7 50V EL. (21SL70) AB
C3008 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21SL70)
C3009 VCEA0A1CW227M J 220 16V EL. (21SL70) AC
C3010 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
(21SL70)
C3011 VCEA0A1HW475M J 4.7 50V EL. (21SL70) AB
C3012 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
(21SL70)
C3013 VCKYCY1HB272K J 2700p 50V Ceramic AA
(21SL70)
PWB-A: DUNTK9882WEV0 (14SL30)
PWB-A: DUNTK9882WEV2 (21SL70)
MAIN UNIT (Continued)
