Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
38
14SL30
21SL40, 21SL70
C3014 RC-QZA473TAYK J 0.047 50V Mylar AB
(21SL70)
C3015 VCSATA1CE335K J 3.3 16V Tantalum AC
(21SL70)
C3016 VCE9GA1HW475M J 4.7 50V EL.(N.P) AB
(21SL70)
C3017 VCSATA1CE106K J 10 16V Tantalum AD
(21SL70)
C3018 VCEA0A1HW105M J 1.0 50V EL. (21SL70) AB
C3019 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21SL70)
C3020 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21SL70)
C3021 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21SL70)
C3022 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21SL70)
C3023 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21SL70)
C3024 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21SL70)
C3025 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21SL70)
C3026 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21SL70)
C3027 VCEAGA1HW225M J 2.2 50V EL. (21SL70) AB
C3028 VCEAGA1HW225M J 2.2 50V EL. (21SL70) AB
C5301 VCEAGA1VW108M J 1000 35V EL. (21SL70) AD
C5304 VCEAGA1HW225M J 2.2 50V EL. (21SL70) AB
C5305 VCEAGA1CW226M J 22 16V EL. (21SL70) AB
C5306 RC-QZA272TAYK J 2700p 50V Mylar AB
(21SL70)
C5307 RC-QZA272TAYK J 2700p 50V Mylar AB
(21SL70)
C5308 VCEAGA1VW107M J 100 35V EL. (21SL70) AC
C5309 VCEAGA1EW108M J 1000 25V EL. (21SL70) AD
C5310 VCEAGA1EW108M J 1000 25V EL. (21SL70) AD
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14SL30)
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(21SL70)
RJ8 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14SL30)
RJ11 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14SL30)
RJ12 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14SL30)
RJ13 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ14 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ17 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ18 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ19 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ20 VRS-CY1JF000J J 0 1/16W M-Ox. AA
å R51 VRS-VV3DB151J J 150 2W M-Ox. AA
R52 VRD-RA2BE1R0J J 1.0 1/8W Carbon AA
å R53 VRS-VV3LB223J J 22k 3W M-Ox. AB
R54 VRD-RA2BE101J J 100 1/8W Carbon AB
R55 VRD-RA2BE101J J 100 1/8W Carbon AB
R56 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R57 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R201 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R202 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R203 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R204 VRS-CY1JF270J J 27 1/16W M-Ox. AA
R205 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R206 VRD-RA2EE151J J 150 1/4W Carbon AA
R208 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R301 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R302 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R303 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R304 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
(21SL70)
R305 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
(21SL70)
R306 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
(21SL70)
R351 VRD-RA2BE223J J 22k 1/8W Carbon AA
(14SL30)
R352 VRD-RA2BE4R7J J 4.7 1/8W Carbon AA
(14SL30)
R355 VRD-RA2BE333J J 33k 1/8W Carbon AA
(14SL30)
R355 VRD-RA2BE101J J 100 1/8W Carbon AB
(21SL70)
R401 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R403 VRS-CY1JF331J J 330 1/16W M-Ox. AA
R404 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R405 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R406 VRS-CY1JF470J J 47 1/16W M-Ox. AA
R407 VRS-CY1JF680J J 68 1/16W M-Ox. AA
R408 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R409 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R410 VRD-RA2BE563J J 56k 1/8W Carbon AA
R411 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R412 VRD-RA2EE561J J 560 1/4W Carbon AA
R413 VRD-RA2BE470J J 47 1/8W Carbon AA
R414 VRD-RA2BE470J J 47 1/8W Carbon AA
R415 VRD-RA2BE470J J 47 1/8W Carbon AA
R416 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R417 VRD-RA2BE101J J 100 1/8W Carbon AB
R418 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R419 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R423 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R426 VRS-CY1JF271J J 270 1/16W M-Ox. AA
R440 VRS-CY1JF821J J 820 1/16W M-Ox. AA
å R451 VRS-VV3AB103J J 10k 1W M-Ox. AA
R452 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R454 VRD-RA2BE334J J 330k 1/8W Carbon AA
R455 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
R456 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R457 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R458 VRD-RA2BE564J J 560k 1/8W Carbon AA
(14SL30)
R458 VRD-RA2BE334J J 330k 1/8W Carbon AA
(21SL70)
R459 VRD-RA2BE123J J 12k 1/8W Carbon AA
R504 VRD-RA2BE471J J 470 1/8W Carbon AA
R505 VRD-RA2BE101J J 100 1/8W Carbon AB
R506 VRD-RA2BE683G J 68k 1/8W Carbon AA
R507 VRD-RA2BE104G J 100k 1/8W Carbon AA
R508 VRD-RA2BE473J J 47k 1/8W Carbon AA
R510 VRD-RM2HD1R5J J 1.5 1/2W Carbon AA
(14SL30)
R510 VRD-RM2HD1R2J J 1.2 1/2W Carbon AA
(21SL70)
å R511 VRN-VV3AB3R9J J 3.9 1W M-Film AA
(14SL30)
å R511 VRN-VV3AB1R5J J 1.5 1W M-Film AA
(21SL70)
R512 VRD-RM2HD271J J 270 1/2W Carbon AA
(14SL30)
R512 VRD-RM2HD331J J 330 1/2W Carbon AA
(21SL70)
R516 VRD-RA2BE153G J 15k 1/8W Carbon AA
(14SL30)
R516 VRD-RA2BE683G J 68k 1/8W Carbon AA
(21SL70)
R517 VRD-RA2BE123G J 12k 1/8W Carbon AA
(14SL30)
R517 VRD-RA2BE103G J 10k 1/8W Carbon AA
(21SL70)
R518 VRD-RA2BE154J J 150k 1/8W Carbon AA
PWB-A: DUNTK9882WEV0 (14SL30)
PWB-A: DUNTK9882WEV2 (21SL70)
MAIN UNIT (Continued)
