Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
40
14SL30
21SL40, 21SL70
R2032 VRD-RA2BE471J J 470 1/8W Carbon AA
R2033 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R2040 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2041 VRD-RA2BE333J J 33k 1/8W Carbon AA
R2042 VRD-RA2BE101J J 100 1/8W Carbon AB
R2043 VRD-RA2BE101J J 100 1/8W Carbon AB
R2044 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2045 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2047 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R2048 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R2049 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2054 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R2055 VRD-RA2BE103J J 10k 1/8W Carbon AA
R2060 VRD-RA2BE221J J 220 1/8W Carbon AA
R2061 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R2062 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R2063 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R2064 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R2066 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2067 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2068 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2070 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2101 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2102 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2201 VRD-RA2EE331J J 330 1/4W Carbon AA
R2501 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2503 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R2504 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2505 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2506 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2507 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R2508 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R2509 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R2601 VRD-RA2BE470J J 47 1/8W Carbon AA
R3001 VRD-RA2BE221J J 220 1/8W Carbon AA
(21SL70)
R3002 VRD-RA2BE221J J 220 1/8W Carbon AA
(21SL70)
R3003 VRS-CY1JF105J J 1.0M 1/16W M-Ox. AA
(21SL70)
R3004 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
(21SL70)
R3005 VRS-CY1JF623J J 62k 1/16W M-Ox. AA
(21SL70)
R3007 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
(21SL70)
R3008 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA
(21SL70)
R3010 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
(21SL70)
R3011 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
(21SL70)
R3012 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
(21SL70)
R5302 VRD-RA2BE123J J 12k 1/8W Carbon AA
(21SL70)
R5303 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
(21SL70)
R5304 VRD-RA2BE103J J 10k 1/8W Carbon AA
(21SL70)
R5305 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
(21SL70)
R5306 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
(21SL70)
R5307 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
(21SL70)
SWITCHES
S2501 QSW-K0079GEZZ J Power AB
S2502 QSW-K0079GEZZ J Vol-Down AB
S2503 QSW-K0079GEZZ J Vol-Up AB
S2504 QSW-K0079GEZZ J Ch-Down AB
S2505 QSW-K0079GEZZ J Ch-Up AB
S2506 QSW-K0079GEZZ J Menu AB
MISCELLANEOUS PARTS
å RY751 RRLYU0045CEZZ J Relay
å F701 QFS-C3229CEZZ J Fuse, 3.15A (125V) AD
FB602 RBLN-0037CEZZ J Ferrite Bead AB
FB603 RBLN-0037CEZZ J Ferrite Bead AB
FB701 RBLN-0037CEZZ J Ferrite Bead AB
FB702 RBLN-0037CEZZ J Ferrite Bead AB
FB703 RBLN-0037CEZZ J Ferrite Bead AB
å FB704 RBLN-0037CEZZ J Ferrite Bead AB
FB751 RBLN-0037CEZZ J Ferrite Bead (14SL30) AB
FB752 RBLN-0037CEZZ J Ferrite Bead AB
FB753 RBLN-0037CEZZ J Ferrite Bead (21SL70) AB
FB754 RBLN-0037CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
P302 QPLGN0461CEZZ J Plug, 4-pin (S) (14SL30) AB
P401 QPLGN0561CEZZ J Plug, 5-pin (GBN) AB
P601 QPLGN0603CEZZ J Plug, 6-pin (K) AB
P651 QPLGN0361CEZZ J Plug, 3-pin AB
P701 QPLGN0269GEZZ J Plug, 2-pin (P) AB
P702 QPLGN0207CEZZ J Plug, 2-pin (M) AA
P751 QPLGN0461CEZZ J Plug, 4-pin (YBN) AB
P998 QPLGN0461CEZZ J Plug, 4-pin (E) (14SL30) AB
P998 QPLGN0661CEZZ J Plug, 6-pin (E) (21SL70) AD
P999 QPLGN0661CEZZ J Plug, 6-pin (D) (21SL70) AD
P2001 QPLGN0561CEZZ J Plug, 5-pin AB
P5301 QPLGN0461CEZZ J Plug, 4-pin (S) (21SL70) AB
RMC2601 RRMCU0222CEZZ J R/C Receiver AL
or
RRMCU0216CEZZ
RDA351 PRDAR0102GJFW X Heat Sink, for IC351
(14SL30)
RDA501 PRDAR0103GJFW X Heat Sink, for IC501 AN
RDA602 PRDAR0216PEFW R Heat Sink, for Q602 AE
(21SL70)
RDA701 PRDAR0260PEFW R Heat Sink, for IC701 AH
RDA754 PRDAR0160PEFW R Heat Sink, for D754 AF
(21SL70)
RDA5301 PRDAR0258PEFW R Heat Sink, for IC5301 AG
(21SL70)
TAN901 QTANJ0523CEZZ J Terminal (21SL70)
LHLDP1042PE00 R Holder AG
LHLDW1002PEZZ R Holder AB
LX-BZ0086TAFD J Screw AA
LX-BZ3100CEFD J Screw AA
LX-TZ3004CEFD J Screw AA
PWB-A: DUNTK9882WEV0 (14SL30)
PWB-A: DUNTK9882WEV2 (21SL70)
MAIN UNIT (Continued)
